11. Ordering information
PRODUCT
MPC3042A
MPC3042AL
ADP2042DIN(N)
ADP2042DIN(P)
ADP2042DIN(R)
ADP9201DIN(R)
ADP9201DIN(N)
ADP9201DIN(P)
ADP9201DIN(S)
JS51050
FVC01
M2668681541
M2668683021
M270325X4
M270325X4S
M270325X0
M270325X0S
M23207
M23209
SM2341104
DESCRIPTIONS
2-axis motion control card for servo/step motor control with pulse referenced
PI control (include SM2341104)
2-axis motion control card for servo/step motor control (include SM2341104)
DIN rail mounted wiring board matched
MPC2042/3042/3042L/3042A/3042AL,General output : 4 power NMOS
DIN rail mounted wiring board matched
MPC2042/3042/3042L/3042A/3042AL,General output : 4 power PMOS
DIN rail mounted wiring board matched
MPC2042/3042/3042L/3042A/3042AL,General output : 4 relays
DIN rail mounted wiring board with 16 I/O LED indicators and relay
output for 8 DI, 8DO
DIN rail mounted wiring board with 16 I/O LED indicators and NMOS
output for 8 DI, 8DO
DIN rail mounted wiring board with 16 I/O LED indicators and PMOS
output for 8 DI, 8DO
DIN rail mounted wiring board with 16 I/O LED indicators and SSR
output for 8 DI, 8DO
DIN rail mounted dummy wiring board (D type 25p male to terminals ) for
JM4
Frequency to voltage module
68-pin SCSI cable 1.5M
68-pin SCSI cable 3.0M
D type 25p male-female cable 1.5M
D type 25p male-female cable 1.5M,shielding
D type 25p male-female cable 3.0M
D type 25p male-female cable 3.0M,shielding
20 pin flat cable 1.5M
20 pin flat cable 3.0M
Extension kit for JM1and JM4
(bracket and flat cable for 9p male D-type and 25p female D-type connector)
