3.2 DIN rail mounted wiring board

ADP2042DIN for JF1 motion control interface
Power Requirement ─ 24Vdc ± 4Vdc
3.2.1
On Board Build-in s.p.s. ─ +5Vdc 500mA (max)
3.2.2
General input ─ 2 with LED indicator
3.2.3
Output capacity ─ 4 NMOS output, 1A continuous、120Vdc(max)
3.2.4
Connection ─ SCSI-II 68 pin cable to connect main and wiring board
3.2.5
Specific servo control connectors ─ 2 D-type 26p (1 per axis)
3.2.6
Operation temperature ─ 0 to 70° C
3.2.7
Operation humidity ─ RH5~95%, non-condensed
3.2.8
Dimension ─ ADP2042DIN(R) / (P) : 121(W)*159(L)*45(H)mm ;
3.2.9
JS51050 for JM4 pulse handler interface
Connection cable ─ D-type 25P cable to connect main and wiring board
3.2.10
Dimension ─ 86(W)*79(L)*52(H)mm, 3.4(W)*3.2(L)*2.1(H)in
3.2.11
ADP9201DIN for ADP9201_JM1 isolated digital I/O
Power Requirement ─ 24Vdc ± 4Vdc
3.2.12
Indicator ─ 8 input and 8 output LED indicators
3.2.13
Output capacity ─ 8 relay output, 3A @250Vac , 3A @30Vdc
3.2.14
Connector ─ 20pin
3.2.15
Operation temperature ─ 0 to 70° C
3.2.16
Operation humidity ─ RH5~95%, non-condensed
3.2.17
Dimension ─ ADP9201DIN(R) / (N) / (P): 86(W) * 103(L) *45(H)mm;
3.2.18
Option : 4 PMOS output, 1A continuous、24Vdc(max)
Option : 4 Relay output, 3A continuous、250Vac(max)
ADP2042DIN(N) : 121(W)*159(L)*47(H)mm ;
Option : 8 NMOS output, 1A @48Vdc
Option : 8 PMOS output, 1A @24Vdc
Option : 8 SSR output, 2A@250Vac
ADP9201DIN(S) : 86(W) * 103(L) *50(H)mm
4.8(W)*6.3(L)*1.8(H)in
4.8(W)*6.3(L)*1.9(H)in
3.4(W)*4.1(L)*1.8(H)in
3.4(W)*4.1(L)*2.0(H)in
