8-6B Chaining Parts (Double Chain) - Coffing Hoists EC3 Series Operating, Maintenance & Parts Manual

FIGURE 8-6B. CHAINING PARTS (DOUBLE CHAIN)
Ref
P/N
No
1 16J9
2 500K12
4 561K19
5 561K18
6 33J13 Sheave Housing, Motor Side (Reference-See figure 8-1)
7 37J6 Sheave Housing, Transmission Side (Reference-See figure 8-1)
8 272J6
9 127J3 Chain Guide Plate Spacer
10 254J3
11 H5393
12 X6477 39
13 H5495P
14 23J5
15 H2219 Socket Head Cap Screw
16 H4063P
17 H5392
18 107JG8 7
20 H6286
21 19J3 Load Chain (Standard)
21 19J3Z Load Chain (Zinc Plated)
Description
Load Sheave
Bearing
Seal
Seal
Chain Guide Plate
Chain Guide
Pin
O Ring
Tail End Pin
Spring
Lockwasher
Dowel Pin
Drive Coupling
Pipe Plug
Ref
Qty P/N
No
1 Bottom Block Assembly (For 3 Ton Hoist) (Consists of Ref No.
22 914JG13
2
Bottom Block Assembly (For 4 Ton Hoist) (Consists of Ref No.
22 914JG14
1
1
23 3M009A03S
1
24 4X1309
1
25 28JG5
2
26 122JG6
3
27 30J10
2
27 30J11
4
28 255J24
4
29 H2419P
1
30 H3966P
1
31 18J5
4
32 285J6
4
33 H1009P
2
34 H1082P
1
35 75J8
1
36 H2376
AR
* 75JG8K
(Consists of Ref No. 35 (2), 36 (2) and instruction Sheet.)
AR
31
Description
23-30)
23-30)
Bottom Hook Assembly with latch
Latch Kit
Chain Sprocket assembly
Sheave Pin assembly
Load Block Frame (For 3 ton Hoists)
Load Block Frame (For 4 ton Hoists)
Sheave Washer
Hex Head Cap Screw
Hex Nut
Dead End Pin
Dead End Pin Retainer
Screw
Lock Washer
7/16" End Stop Frame
Screw
7/16" End Stop Kit
EC3-680-3 February 2017
Order # 5041558-0 & 5041679-0
Qty
1
1
1
1
1
1
2
2
2
1
1
1
1
1
1
