8-6A Chaining Parts (Single Chain) - Coffing Hoists EC3 Series Operating, Maintenance & Parts Manual

FIGURE 8-6A. CHAINING PARTS (SINGLE CHAIN)
Ref
P/N
No
1 16J9
2 500K12
4 561K19
5 561K18
6 33J13 Sheave Housing, Motor Side (Reference-See figure 8-1)
7 37J6 Sheave Housing, Transmission Side (Reference-See figure 8-1)
8 272J6
9 127J3 Chain Guide Plate Spacer
10 254J3
11 H5393
12 X6477 39
13 H5495P
14 23J5
15 H2219 Socket Head Cap Screw
16 H4063P
17 H5392
Description
Load Sheave
Bearing
Seal
Seal
Chain Guide Plate
Chain Guide
Pin
O Ring
Tail End Pin
Spring
Lockwasher
Dowel Pin
Ref
Qty P/N
No
1 18 107JG8 7
20 H6286
2
21 19J3
1
21 19J3Z
1
22 913JG2 Bottom Block Assembly (Consists of Ref No. 23-29)
1
23 30J9
1
24 18J7
2
25 S44 33
3
26 H3978
2
27 H4157
4
28 3M007C01S
4
29 4X1307
1
30 75J8
1
31 H2376
4
4
* 75JG8K
(Consists of Ref No. 30 (2), 31 (2) and instruction Sheet.)
2
30
Description
Drive Coupling
Pipe Plug
Load Chain (Standard)
Load Chain (Zinc Plated)
Load Block Frame
Pin
Screw
Nut
Lock Washer
Bottom Hook Assembly with latch
Latch Kit
7/16" End Stop Frame
Screw
7/16" End Stop Kit
EC3-680-3 February 2017
Order # 5041558-0 & 5041679-0
Qty
1
1
AR
AR
2
1
2
2
2
1
1
2
2
