- Page 1 I N S T R U C T I O N M A N U A L Model:2190...
-
Page 2: Assembly Guide
ASSEMBLY GUIDE Congratulations, you are now the owner of a brand new STARSPACE chair! Before enjoy the comfort chair, you have to put it together.This Assembly Guide will take you through the basic assembly process. To make sure your assembly goes smoothly, please follow the assembly instructions, especially the important safety information. -
Page 3: Package List
service@colamychair.com www.colamychair.com PACKAGE LIST Casters Star Base Lift Cover Quantity: 5 Quantity: 1 Quantity: 1 Lift Seat Plate Seat Cushion Quantity: 1 Quantity: 1 Quantity: 1 Bolts M8*25mm Bolts M6*20mm Back Cushion Quantity: 4 Quantity: 10 Quantity: 1 Arms Plastic Caps Wrench Quantity: 2 Quantity: 9... -
Page 4: Assembly Instruction
service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 1 : Turn the Star Base(B) upside down, then press the Casters(A) into the holes at the end of each base leg, insert the Lift(C) into the center hole of the Star Base ， the Lift Cover(C) should be placed over the Lift. - Page 5 service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 2 : Align the Seat Plate over the pre-drilled holes underneath the Seat Cushion, make sure that the front of the seat plate is facing the front of the Seat Cushion. Attach the Seat Plate(E) to the Seat Cushion(F) using Four Bolts M8*25mm(G) , tighten all the bolts with the Wrench(K), being careful not to miss-thread the bolts or damaged the seat.
- Page 6 service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 3 : Turn the Seat Cushion upright and align the center hole of the Seat Plate over the lift, then push the Seat Cushion down onto the lift firmly until the connection is secure.
- Page 7 service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 4 : Attach the Arms(I) to the Seat Cushion(E) with Four Bolts M6*20mm(G1), using the Wrench(K). Note 1: Arm rests are labeled with an "L" (left) or "R" (right) to show which sides they should be placed on. Note 2: Do not tighten all the bolts to 100%, 50% is enough, make sure it have space to adjust in the next steps.
- Page 8 service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 5 : Lay the Back Cushion on the seat of the chair with the top of the cushion toward the front. Attach the Back Cushion(H) to the Arms(I) by inserting Two Bolts M6*20mm(G1) in the Lower holes with the Wrench(K). Note 1: Do not tighten all the bolts to 100%, 50% is enough, make sure it have space to adjust in the next steps.
- Page 9 service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 6 : Rotate the back of the chair up, then secure it with the Top Two Bolts M6*20mm(G1) with the Wrench(K). Adjust the balance on each side of the chair, and fully tighten all the bolts at this step.
- Page 10 service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 7 : Align the control handles of the back adjust over the pre-drilled holes underneath the Seat Cushion(F), attach the handle to the Seat Cushion using Two Bolts M6*20mm(G1), tighten all the bolts with the Wrench(K).
- Page 11 service@colamychair.com www.colamychair.com ASSEMBLY INSTRUCTION STEP 8 : Press the Plastic Caps(J) into the Arms holes to cover the bolts. CAUTION: Make sure all bolts and screws are fully tightened before using chair. Lubricate all moving parts and tighten all bolts/screws every 6 month or whenever needed.
- Page 12 service@colamychair.com www.colamychair.com INSTRUCTIONS FOR USE 1.Seat Height:Paddle-shaped lever on the right side To raise: While taking your weight off chair, lift lever up. To lower: While seated, lift lever up. At the proper height, your feet should rest flat on the floor. 2.Tilt Tension: Long stem under the seat cushion with knob To increase tension: While seated, turn knob forward...
- Page 13 service@colamychair.com www.colamychair.com INSTRUCTIONS FOR USE 3.Operating the tilt lockout- Paddle-shaped lever on left side. Push up to unlock the tilt mechanism. Pull down to lock the tilt mechanism.
-
Page 14: Safety And Maintenance
service@colamychair.com www.colamychair.com SAFETY AND MAINTENANCE Do not stand on the chair, Do Not use the chair as stepladder. Use this product for seating one person at a time. Do not use the chair unless all bolts and screws are firmly secured. Avoid contact with sharp objects to prevent puncturing the fabric. -
Page 15: Limited Warranty
LIMITED WARRANTY STARSPACE promises to repair or replace any STARSPACE chair that is found to be defective in material or workmanship within one (1) year from the date of original purchase so long as you, the original purchaser, still owns it. - Page 16 service@colamychair.com www.colamychair.com RETURN POLICY ： We adopt a 30 days return policy which means that all products purchased on this website may be returned to us within the timeframe. You need to contact us within 30 days after the product(s) came into your possession and the product(s) must be returned to us without any undue delays.
- Page 17 Website: www.colamychair.com Email: service@colamychair.com...
