COP-USA CC35NVD Specifications

CC35NVD - 520TVL High Resolution IR Sensitive Camera
Pick-up device:
Picture elements :
Horizontal resolution:
Minimun Illumination:
Horizontal Sync. frequency:
Vertical frequency :
Clock frequency:
Scanning system:
Electronic shutter:
Video output:
Power supply :
Power Consumption:
Storage Temperature :
Operation Temperature :
1/3" SONY High Resolution DSP Color CCD
EIA/NTSC: 512 H x 492 V - CCIR/PAL: 512 H x 582 V
520 TVL
0.1 Lux DAY & NIGHT IR SENSITIVE
EIA//NTSC: 15.734 KHZ - CCIR/PAL: 15.625 KHZ
EIA//NTSC: 60 HZ - CCIR/PAL: 50 HZ
EIA//NTSC: 19.0699 MHZ - CCIR/PAL: 18.9375 MHZ
2:1 interlace
EIA//NTSC: 1/60 ~ 1/100.000sec - CCIR/PAL: 1/50 ~ 1/100.000sec
1Vp-p , 75 Ohms
DC12V (Dual Power DC12V - AC24V)
150 mA
-30°C ~ 60°C
-10°C ~ 45°C
* Pictures and specifications are subject to change without prior notice
