COP-USA CC25NVD Specifications

CC25NVD - 480TVL HIGH RESOLUTION IR SENSITIVE CAMERA
Type:
Image Pick-Up Device:
Picture Elements:
Resolution:
Mini Illumination:
Horiz. Sync. Frequency:
Vertical Frequency:
Clock Frequency:
Scanning System:
Video Output:
Power Supply:
Power Consumption:
Storage Temperature:
Operating Temperature:
Color
1/3" HIGH RESOLUTION DSP CCD Image Sensor
512(H) x 492 (V), NTSC/EIA / 512(H) x 582 (V) PAL/CCIR
480 Horizontal TV Lines
0.1 Lux Day & Night IR Sensitive
NTSC/EIA 15,734KHz, CCIR/PAL 15,625KHz
NTSC/EIA 60Hz, CCIR/PAL 50Hz
NTSC/EIA 19.0699MHz, CCIR/PAL 18.9375MHz
Interlace 2:1
1Vp-p, 75 Ohms
Dual power DC12V and AC24V
150mA
-30 to 60°C
-10 to 45°C
* Pictures and specifications are subject to change without prior notice
