EASYPACK

QUANTUM SERIES

PAPER PACKAGING BY PREGIS

User Manual v1.2

Table of Contents

Need help?

Do you have a question about the EASYPACK QUANTUM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Pregis EASYPACK QUANTUM Series

Page 2: Table Of Contents
XTW Specifications ..…………………………………16 Introduction The Pregis Quantum Series includes the Quantum XT and Quantum XTW systems. Each system dispenses recycled paper void fill both on demand and at predetermined lengths, as needed. These user-friendly systems save storage space and reduce packaging material waste while providing unmatched safety, reliability and enhanced ergonomic features that increase operator productivity.
Page 3: General Safety
Please read and understand the manual including all of the danger, warnings, and caution statements. If after reading the manual you have questions, contact your supervisor or your Pregis service technician to get answers before working with the machine.
Page 4: Understanding The Controls
Understanding the Controls The Power Switch for the Quantum Series is used to turn the electrical power “ON” or “OFF” and is located on the right side of the head assembly, next to the power inlet. Power Switch [“I” = On, “O” = Off] Power Inlet Foot Pedal Jack When operating the Quantum Series, the most commonly used component is the foot pedal...
Page 5 Head Assembly Controls...
Page 6: Operation
Operation 1. DO NOT attempt to defeat any safety feature. 2. DO NOT place any part of your person or foreign object into the drive. 3. Keep clear of all pinch points while machine is running. 4. DO NOT operate the machine if any part of your body becomes fatigued. 5.
Page 7 Manual Feed-to-Length (FTL) Mode The manual feed-to-length (FTL) setting allows the operator to dispense a preset length of material by activating the foot pedal briefly (i.e. “tapping” the foot pedal). Once the foot pedal is “tapped” (activated briefly) the machine will dispense a preset length of material. The operator must repeat the process to receive additional, preset lengths of material.
Page 8 Auto Feed-to-Length (A-FTL) Mode The auto feed-to-length (A-FTL) setting allows the operator to dispense a preset length of material. Once the powered tear assist feature is activated (see Powered Tear Assist section), the machine will automatically dispense another preset length of material (same as previous). This process will continue as long as the feature is active.
Page 9 Powered Tear Assist (PTA) The powered tear assist (PTA) feature was designed to reduce the amount of force it takes to tear the void fill material. Once material has been dispensed, the powered tear assist feature becomes active. To use this feature, simply pull the void fill material against the tear assist in a downward motion as shown below.
Page 10 Quantum XT Loading (Pull from Center Paper) 1. Place a roll of Quantum paper into 2. Pull out the overlapped material the roll cradle (roll core) and either unroll or tear off the material (save for later use). 3. Lift the upper-roller assembly. 4.
Page 11 Quantum XTW Magazine Loading (Fanfold Paper)
Page 12 Quantum XTW Magazine Loading (Fanfold Paper) Cont’d...
Page 13: Maintenance
Quantum Series operating correctly and minimize any down time on your packaging line. If there are any questions regarding the maintenance of the Quantum Series, please contact your local Pregis Service Technician for assistance.
Page 14: Trouble Shooting
Problem: Machine is powered on but will not run. Cause: Head assembly cables/foot pedal cable not connected properly. Solution: Verify cable connections. Problem: Upper roller assembly keeps “popping up” while running material. Cause: Magnet block assembly not properly adjusted. Solution: Contact Pregis Service 1 866-904-6979...
Page 15: Xt Specifications
Quantum XT Machine Specifications Machine Weight: 35 lbs Machine and Floor Stand: 75 lbs Power Requirements: 3 Amps Side Profile Overhead...
Page 16: Xtw Specifications
Quantum XTW Machine Specifications Machine Weight: 35 lbs Machine and Floor Stand: 75 lbs Magazine Weight (Un-loaded): 115 lbs Power Requirements: 3 Amps Front Side Profile Overhead...
