- Page 1 Quantum ™ User Manual Revision C...
-
Page 2: Table Of Contents
LANGUAGES OF OPERATION DISCLAIMER The original version of this manual is in English and denoted “Original Instructions” in the top center header. All translated versions are denoted “Translation of Original Instructions” in the same location. June 2022 Copyright Pregis LLC All Rights Reserved... - Page 3 Quantum™ Pro User Manual Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries) Original Instructions Property of Pregis LLC 227 W Monroe St Suite 4100 Chicago, IL 60606 United States of America Authorized CE Representative ACC –...
-
Page 4: Introduction
Item # Formulation Bundle Width Bundle Length 4068969 30-in 1,690-ft 4068622 15-in 1,690-ft 4077694 15-in 1,340-ft 4079017 50-gsm 750-mm 515-m 4079015 50-gsm 375-mm 515-m 4079016 70-gsm 375-mm 408-m 4074239 52-gsm 375-mm 515-m June 2022 Copyright Pregis LLC All Rights Reserved... -
Page 5: General Safety
If after reading the manual you have questions, contact your supervisor or your Pregis service technician to get answers before working with the machine. 1. Only authorized personnel may use the equipment. -
Page 6: Assembly And Inspection
Assembly and Inspection Parts to be assembled and inspected by Pregis technicians. If machine requires maintenance or repair, contact Pregis Tech Service Hotline Understanding the Controls The Power Switch for the Quantum Series is used to turn the electrical power “ON” or “OFF” and is located on the right side of the head assembly, next to the power inlet. -
Page 7: Head Assembly Controls
4. DO NOT operate the machine if you are under the influence of alcohol, drugs or medications that can make you less alert or affect your judgment. Operating Modes: • Manual Mode • Manual Feed-to-Length (FTL) Mode • Auto Feed-to-Length (A-FTL) Mode June 2022 Copyright Pregis LLC All Rights Reserved... -
Page 8: Manual Mode
Original Instructions 4.1 Manual Mode: The manual setting allows the operator to dispense material using the foot pedal only. In this mode, machine speed can be adjusted to user preference as needed. June 2022 Copyright Pregis LLC All Rights Reserved... -
Page 9: Manual Feed-To-Length (Ftl) Mode
The preset length can be adjusted (using the add/subtract buttons on head assembly) as needed. June 2022 Copyright Pregis LLC All Rights Reserved... -
Page 10: Auto Feed-To-Length (A-Ftl) Mode
To receive a length of material greater than the preset length, press and hold the foot pedal until the desired length is received. The preset length can be adjusted (using the add/subtract buttons on head assembly) as needed. June 2022 Copyright Pregis LLC All Rights Reserved... - Page 11 EasyPack ® Quantum™ Pro User Manual Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries) Original Instructions June 2022 Copyright Pregis LLC All Rights Reserved...
-
Page 12: Quantum Magazine Loading (Fanfold Paper)
® Quantum™ Pro User Manual Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries) Original Instructions Quantum Magazine Loading (Fanfold Paper) June 2022 Copyright Pregis LLC All Rights Reserved... - Page 13 EasyPack ® Quantum™ Pro User Manual Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries) Original Instructions June 2022 Copyright Pregis LLC All Rights Reserved...
-
Page 14: Quantum Pro Stand Height Adjustment
® Quantum™ Pro User Manual Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries) Original Instructions Quantum Pro Stand Height Adjustment June 2022 Copyright Pregis LLC All Rights Reserved... -
Page 15: Maintenance
Disconnect the power cord before performing ANY maintenance to the machine other than inspections. Monthly Maintenance: 1. Machine should be cleaned periodically to maintain a clean work environment. 2. Verify all components are working properly. If there are any issues, please contact your Pregis Service Technician. June 2022... -
Page 16: Error Descriptions
AFTL paper during the dispense This error only occurs when operating in cycle. AFTL mode *Open and close duckbill to clear error messages. If errors persist, call Pregis Tech Service Hotline June 2022 Copyright Pregis LLC All Rights Reserved... -
Page 17: Troubleshooting
Paper not tearing Maintenance required. Call Pregis Service Upper roller assembly keeps Magnet block assembly not Call Pregis Service popping up while running properly adjusted material If problems persist, call Pregis Tech Service Hotline June 2022 Copyright Pregis LLC All Rights Reserved... -
Page 18: Machine Specifications
Machine and Floor Stand: 69 lbs (31.75 kg) Magazine Weight (Un-loaded): 95 lbs (43.09 kg) Power Requirements: 120/230 VAC, 60/50 Hz, 3.3/1.3 A Sounds Pressure Level Leq: 73.5 dB(A) 30” Magazine Overall Dimensions Front Side Profile Overhead Opened June 2022 Copyright Pregis LLC All Rights Reserved... - Page 19 Quantum™ Pro User Manual Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries) Original Instructions 30” Tray Overall Dimensions Front Side Profile Overhead Opened June 2022 Copyright Pregis LLC All Rights Reserved...
- Page 20 Quantum™ Pro User Manual Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries) Original Instructions 15” Magazine and Tray Reference Dimensions Front Front June 2022 Copyright Pregis LLC All Rights Reserved...
-
Page 21: Revision Table
00800 888 888 44 (All other European Countries) Original Instructions 11 Revision Table REV BY DATE ECN DESCRIPTION NUMBER 02 NOV 2022 INITIAL RELEASE 03 NOV 2022 UPDATED ERROR DESCRIPTIONS (PAGE 13) 07 FEB 2023 UPDATED FORMATTING EC-1812 June 2022 Copyright Pregis LLC All Rights Reserved...
