CNET CSH-24X2G Specifications

TOTAL NETWORK SOLUTIONS
CSH-24X2Gm implements 24 10/100Mbps TP ports as well as 2 copper/fiber module slots. The switch is
specifically designed for MTU application and is fully compliant with IEEE 802.3/u/x/z/ab standards. With built-in
SNMP agent and web-based management, network administrator can easily logon to the switch to monitor, and
configure its operation and settings.

KEY FEATURES

=
Supports up to 256 active tagged VLANs
=
Supports up to 256 IP multicast table entries
=
Supports 802.1p priority QoS
=
Supports per port bandwidth rating
=
Supports Text-/Web-based and SNMP Manager
management
=
Supports Telnet, HTTPd, TFTP, DHCP Client, SMTP
=
Supports MIB II, Bridge MIB, Ethernet MIB, Enterprise
MIB, RMON MIB group 1,2,3,9
=
Back-pressure flow-control for half-duplex mode
=
Supports in-band/out-of-band management
=
Supports 2 Hot-Swappable modules slots for various
Ethernet media
=
Per port external Loop-back capability
=
IP Multicast: IGMP snooping (with reporting)
=
Supports up to 6 Fast Ethernet ports Trunkings and 1
Gigabit Ethernet versatile port Trunking
=
Supports illegal intrusion/access report

SPECIFICATIONS

Product Name
Model Name
Standards
Ports
Fiber
Forwarding / Filtering Rate
LED Indicators
Environment
Power Supply
Certifications
Dimensions
CSH-24X2Gm(B)
Specifications are subject to change without notice
CSH-24X2Gm– (24 + 2) Layer 2 Management Switch
Layer 2 Management Switch with 24 10/100Base-TX Ports Optional with 2 Module Slots
CSH-24X2Gm
IEEE 802.3: 10Base-T, IEEE 802.3u :100Base-TX, IEEE 802.3ab: 1000Base-T, IEEE 802.3z :1000Base-X
IEEE 802.3x : Full-Duplex flow control, IEEE 802.1p: Class-of-Service, IEEE 802.1Q: VLAN
24 Ports 100Base-TX
1 or 2 port(s) 100Base-FX (Optional)
1 or 2 port(s) 1000Base-FX (Optional)
Single-Mode / Multi-Mode
148,000 packets/sec full wire rate on 100Mbps
Power, Link/ACT, 100Mbps, FDX/COL
Operating Temperature: -20° ~ 70° C (-4° ~ 158° F)
Storage Temperature: -40° ~ 80° C (-40° ~ 176° F)
Humidity: 10% ~ 90% Non-condensing
Internal Full Range Auto-switching
Input Voltage: 100-240 +/- 10% AC/50~60Hz
CE, FCC
442 x 203 x 46 mm (17.4 x 7.99 x 1.81 inches)
www.cnetusa.com
=
Supports port-pairs failover
=
Supports SNMP and RMON probing
=
Supports Short Message (SMS) and email for trap and
alarm
=
Supports System log
Trademarks & Trade Names belong to their owners
Feb, 2005
