CNET CSH-1600 Product Specifications

TOTAL NETWORK SOLUTIONS
The CNet 16 port web managed switch is any network administrator's dream come through. Using this switch along
with the CNet management utility, the whole network of CSH-1600 or any of the CNet web switches are at the fingertip
of the network administrator. Using the browser, all web managed CNet switches are now available for view,
reconfiguration or troubleshooting all at the same time and from a central location.

KEY FEATURES

Up to 16 Port based VLAN groups
Support ToS priority setting
Support QoS priority ratio setting
Independent bandwidth for each port
Store-and-Forward switching technology
Auto MDI/MDIX function supported
IEEE 802.3x Flow-Control supports for Full-Duplex
operation
Back-Pressure function supports for Half-Duplex
operation
PRODUCT SPECIFICATIONS
Model
10BASE-T IEEE 802.3
Standards 100BASE-TX IEEE 802.3u
IEEE 802.3x Flow Control for Full-Duplex operation
Ports 16 100BASE-TX/10BASE-T
10BASE-T Category 3, 4 or 5 TP
Media Support
100BASE-TX Category 5 TP
100BASE-TX - 200/100Mbps
Bandwidth
10BASE-T - 20/10Mbps
Forwarding/Filtering 148,800 packets/second per port @ 100Mbps, max.
Rate 14,880 packets/second per port @ 10Mbps, max.
Configuration
IE Web browser
Interface
Auto-MDIX All TP ports support Auto-MDI/MDIX function
One (1) for Power
LED Indicators One (1) per port for Link/ACT
One (1) per port for Full-Duplex or Collision
Internal full range switching power supply
Power Supply
Input voltage: 100 ~ 240 +/-10%V AC, 50/60 Hz
Power Consumption 15 watt max.
Operating Temp: 0 ~ 45 C (32 ~ 113 F)
Environment Storage Temp: -20 ~ 70 C (-4 ~ 158 F)
Humidity: 10% ~ 90% non-condensing
Dimensions 442 x 185 x 44 mm (17.40 x 7.28 x 1.73 inches)

Ordering Information

Model
CSH-1600W (B) 16 Ports Smart Access Web Management Switch
CSH-1600W(B)
Specifications are subject to change without notice
CSH-1600W – 16 Ports Smart Access Web Management Switch
CSH-1600W
www.cnetusa.com
Description
