2.
RUGGEDCOM RS900L
Installation Manual, 04/2021, C79000-G8976-1027-09
Connect the positive wire from the power source to the positive/live (+/L)
terminal on the terminal block.
1
2
3
Positive/Live (+/L) Terminal
1
Negative/Neutral (-/N) Terminal
2
Surge Ground Terminal
3
Braided Ground Cable
4
Figure 2.5
Terminal Block Wiring
Installing the Device
2.6.1 Connecting High AC/DC Power
4
15
