(3 WIRES 120/240 – 60 – 1)
MULTI POSITION
INSTALLER / SERVICE TECHNICIAN:
USE THE INFORMATION IN THIS MANUAL FOR THE INSTALLATION AND
SERVICING OF THE FURNACE AND KEEP THE DOCUMENT NEAR THE
UNIT FOR FUTURE REFERENCE.
HOMEOWNER:
PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR FUTURE
REFERENCE.
Printed in Canada
Printed on 100% recycled paper
Models:
SUP10-M2401A
SUP15-M2401A
SUP18-M2401A
SUP20-M2401A
SUP23-M2401A
SUP20-M2401B
SUP23-M2401B
SUP27-M2401B
Caution: Do not tamper with
the unit or its controls. Call a
qualified service technician.
Manufactured by:
Industries Dettson inc.
3400 Industrial Boulevard
Sherbrooke, Quebec - Canada
J1L 1V8
2013-10-24
X40208 Rev. D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dettson SUPREME SUP10-M2401A
Summary of Contents for Dettson SUPREME SUP10-M2401A
- Page 1 USE THE INFORMATION IN THIS MANUAL FOR THE INSTALLATION AND SERVICING OF THE FURNACE AND KEEP THE DOCUMENT NEAR THE Manufactured by: UNIT FOR FUTURE REFERENCE. Industries Dettson inc. HOMEOWNER: 3400 Industrial Boulevard Sherbrooke, Quebec - Canada PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR FUTURE J1L 1V8 REFERENCE.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLES Table 1: Supply air adjustment on heating mode....6 SAFETY..............3 Table 2: Supply air adjustment on air cooling mode .....6 DANGER, WARNING AND CAUTION....3 Table 3 : Technical specifications ........10 IMPORTANT INFORMATION ........ 3 Table 4 : Airflow (CFM) - SUPREME with 1/3HP motor..10 DANGER OF FREEZING ........ -
Page 3: Safety
SAFETY Ask the technician installing your furnace to show and explain to you the following items: The main disconnect switch or circuit breaker; DANGER, WARNING AND CAUTION The air filter and how to change it (check The words DANGER, WARNING and CAUTION are used to monthly and clean or replace if necessary);... -
Page 4: Positioning The Furnace
If the static pressure is high in the supply duct because of a CONFIGURATIONS large duct system or the addition of a cooling coil, it is This furnace requires suitable ductwork. suggested to close down the louvers until the noise or the In upflow installation, the return duct may be installed to the vibration is decreased to a normal level. -
Page 5: Horizontal Installation
wiring diagrams provided with the heating/air conditioning unit. The connections must be made as indicated on Horizontal installation 2.3.3. Figures 4 to 8 diagrams and on electrical diagrams (Figures The return duct may be installed to the back, on the left side, 10 to 14). -
Page 6: Ducts And Filters
Figure 6: 1-stage thermostat with outdoor control for 2- The SUPREME furnace is equipped with a filter frame for the stage function, electric heating only blower compartment. It must be installed on the outside of one of the three sides or the bottom of the furnace. Once the location of the installation has been determined, use the four square knockouts for ease of cutting the opening. -
Page 7: Installation Of Accessories
If the heating and air-cooling speed are the same, the red The thermostat of the room is in the heating mode and wire and the blue wire can be connected on the same is set higher than the ambient temperature. terminal on the motor. -
Page 8: Cooling Mode
The 24 VAC relay of the heating speed is also activated CAUTION and heating blower speed start. 3.3.2. Cooling mode It is important to check the airflow and to ascertain that the unit does not operate above the temperatures The thermostat closes the R-G circuit, thereby activating specified in the Technical Specifications (Table 2). -
Page 9: Furnace Information
FURNACE INFORMATION Model: Serial number: Furnace installation date: Service telephone # - Day: Night: Dealer name and address: START-UP RESULTS Voltage: Total current consumed by the elements: Supply air temperature: Return air temperature: Supply air duct static pressure: Return air duct static pressure: Total pressure: Calculated air flow: Current consumed by the blower motor:... -
Page 10: Table 3 : Technical Specifications
Table 3 : Technical specifications SUPxx-M2401A SUPxx-M2401B RATINGS AND PERFORMANCE Power, total (Kw) Power, first stage (Kw) Net capacity (BTU/h) 34 120 51 180 61 420 68 240 78 480 68 240 78 480 78 480 92 130 Heating temperature rise range (F) 40-50 45-60 50-75... -
Page 11: Figure 9 : Furnace Dimensions
Figure 9 : Furnace dimensions... -
Page 12: Figure 10 : Wiring Diagram, 3 Wires (10 Kw)
Figure 10 : Wiring diagram, 3 wires (10 kW) -
Page 13: Figure 11 : Wiring Diagram, 3 Wires (15 Kw)
Figure 11 : Wiring diagram, 3 wires (15 kW) -
Page 14: Figure 12 : Wiring Diagram, 3 Wires (18 & 20 Kw)
Figure 12 : Wiring diagram, 3 wires (18 & 20 kW) -
Page 15: Figure 13 : Wiring Diagram, 3 Wires (23 Kw)
Figure 13 : Wiring diagram, 3 wires (23 kW) -
Page 16: Figure 14 : Wiring Diagram, 3 Wires (27 Kw)
Figure 14 : Wiring diagram, 3 wires (27 kW) -
Page 17: Figure 15 : Parts List, Supreme With 1/3 Hp And 1 Hp
Figure 15 : PARTS LIST, Supreme with 1/3 HP and 1 HP motor: SUPxx-M2401A or SUPxx-M2401B B50130A.dwg... -
Page 18: Table 6 : Parts List, Supreme With
Table 6: PARTS LIST, Supreme with 1/3 HP and 1 HP motor: SUPxx-M2401A or SUPxx-M2401B ITEM PART # DESCRIPTION COMMENTS B04114-01 HEATING ELEMENT PLATE ASSEMBLY SUP10kw (1/3 HP) Item 12 included B04115-01 HEATING ELEMENT PLATE ASSEMBLY SUP15kw (1/3 HP) Item 12 included B04116-01 HEATING ELEMENT PLATE ASSEMBLY SUP18kw (1/3 HP) Item 12 included B04116-02 HEATING ELEMENT PLATE ASSEMBLY SUP20kw (1/3 HP / 1 HP)
