Dettson AMP105-IE2 Installation Instructions And Homeowner's Manual
Warm air furnace multiposition
Hide thumbs
Also See for AMP105-IE2:
Table of Contents
Advertisement
Quick Links
WARM AIR FURNACE
MULTIPOSITION
INSTALLER / SERVICE TECHNICIAN:
USE
THE
INFORMATION
INSTALLATION / SERVICING OF THE FURNACE AND KEEP
THE DOCUMENT NEAR THE UNIT FOR FUTURE REFERENCE.
HOMEOWNER:
PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR
FUTURE REFERENCE.
Printed in Canada
Printed on 100% recycled paper
IN
THIS
MANUAL
Models:
AMP105-IE2
AMP120-IE2
NOMF105D12C
NOMF155E19C
NOMF106D12B
NOMF156E19C
Attention:
Do not tamper with the unit or its
controls.
FOR
THE
Call a qualified service technician.
Manufactured by:
Dettson Industries inc.
3400 Industriel Boulevard
Sherbrooke, Qc – Canada – J1L 1V8
www.dettson.ca
2012-02-07
C
US
X40002 Rev.X
