KITO TCR Series Owner's Manual

Air powered chain hoist ¼ tonne through 6 tonne capacity
Hide thumbs
Table of Contents

Advertisement

Quick Links

BULLETIN NO. TCROM-0913-04
Owner's Manual
AIR
POWERED
CHAIN HOIST
TCR SERIES
¼ tonne through 6 tonne Capacity
Code Number and Serial Number

This equipment should not be installed, operated or
maintained by any person who has not read and understood
all the contents of this manual. Failure to read and comply
with the contents of this manual can result in serious bodily
injury or death, and/or property damage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KITO TCR Series

Summary of Contents for KITO TCR Series

  • Page 1 BULLETIN NO. TCROM-0913-04 Owner’s Manual POWERED CHAIN HOIST TCR SERIES ¼ tonne through 6 tonne Capacity Code Number and Serial Number  This equipment should not be installed, operated or maintained by any person who has not read and understood all the contents of this manual.

  • Page 2: Table Of Contents

    Table of Contents Section Page Number Important Information and Warnings…………………………………………………………………4 Terms and Summary Warning Tags and Labels Technical Information………………………………………………………………………………… 8 Specifications Dimensions Part Names Pre-operational Procedures………………………………………………………………………... 19 Air Supply System Requirements Air Supply Capacity And Regulation Lubrication Filtration Air Dryer Piping, Hoses And Fittings Mounting Location Connecting Hoist to Air Supply...
  • Page 3 Table of Contents Section Page Number Inspection……………………………………………………………………………………………. 33 General Inspection Classification Frequent Inspection Periodic Inspection Occasionally Used Hoists Inspection Records Inspection Methods and Criteria Lubrication…………………………………………………………………………………………... 40 Air Hoist Lubrication Load Chain Lubrication Hooks and Suspension Components Maintenance & Handling…………………………………………………………………………… 41 Load Limiter Brake Load Chain...

  • Page 4: Important Information And Warnings

    Record your hoist’s Code and Serial Number on the front cover of this manual for identification and future reference to avoid referring to the wrong manual for information or instructions on installation, operation, inspection, maintenance, or parts. Use only Kito authorized replacement parts in the service and maintenance of this hoist.
  • Page 5 WARNING! Equipment described herein is not designed for and MUST NOT be used for lifting, supporting, or transporting people, or for lifting or supporting loads over people. Equipment described herein should not be used in conjunction with other equipment unless necessary and/or required safety devices applicable to the system, crane, or application are installed by the system designer, system manufacturer, crane manufacturer, installer, or user.
  • Page 6 If the hoist owner/user requires additional information, or if any information in the manual is not clear, contact Kito or the distributor of the hoist. Do not install, inspect, test, maintain, or operate this hoist unless this information is fully understood.

  • Page 7: Warning Tags And Labels

    Warning Tags and Labels The warning tag illustrated below in Figure 1-1 is supplied with each hoist shipped from the factory. If the tag is not attached to your hoist (for pendant control, the warning tag is attached to the pendant hose; for the pull cord control, the warning tag is attached to the up cord), order a tag from your dealer and install it.

  • Page 8: 2.0 Technical Information

    2.0 Technical Information Specifications 2.1.1 Product Code 2.1.2 Operating Conditions and Environment Temperature range: -10° to +60°C (+14° to +140°F) Relative Humidity: 85% or less Noise Level: 92 dba maximum @ 1 meter when lifting rated load 95 dba maximum @ 1 meter when lowering rated load Supply Air: 60 to 90 pounds per square inch Air Consumption:...

  • Page 9: Dimensions

    Table 2-1 Hoist Specifications Up/Down Load Chain Push Up/Down Speeds Air Consumption Rates Diameter Weight for Standard Button (ft/min @ 90 psi) Cap. Product (mm) Additional (cubic ft/min @ 90 psi) Lift Hose Weight (tonne) Code 5 ft of Lift (ft) (lbs) Chain Fall...
  • Page 10 Table 2-3 TCR with Pendant Control Dimensions Headroom Cap. Product (Tons) Code (in) (in) (in) (in) (in) (in) (in) (in) (in) TCR250P 11.3 TCR500P 18.2 13.4 TCR1000P2 20.4 13.4 TCR1000P 18.3 13.4 TCR2000P2 21.8 13.4 TCR3000P 22.2 17.7 TCR6000P2 26.5 17.7 11.1 Single Fall Hoist Double Fall Hoist...
  • Page 11 Table 2-4 TCR with Cord Control Dimensions Headroom Cap. Product (Tons) Code (in) (in) (in) (in) (in) (in) (in) (in) (in) (in) TCR250C 11.3 TCR500C 18.2 13.4 TCR1000C2 20.4 13.4 TCR1000C 18.3 13.4 TCR2000C2 21.8 13.4 TCR3000C 22.2 17.7 TCR6000C2 26.5 17.7 11.1 Single Fall Hoist...
  • Page 12 Figure 2-3 Dimensions for Manipulator TCR250 Air Hoist (inches)

  • Page 13: Part Names

    Part Names Figure 2-4 Hoist Part Identification Diagrams TCR500P, 500C, 1000P, 1000C...
  • Page 14 Figure 2-5 Hoist Part Identification Diagrams TCR 1000P2, 1000C2, 2000P2, 2000C2...
  • Page 15 Figure 2-6 Hoist Part Identification Diagrams TCR 3000P, 3000C Figure 2-7 Hoist Part Identification Diagrams TCR 6000P2, 6000C2...
  • Page 16 Top hook Bottom hook Figure 2-8 Hoist Part Identification Diagrams TCR250C...
  • Page 17 Top hook Bottom hook Figure 2-9 Hoist Part Identification Diagrams TCR250P...
  • Page 18 Top hook Bottom hook Figure 2-10 Hoist Part Identification Diagrams TCR250M...

  • Page 19: 3.0 Preoperational Procedures

    3.0 Preoperational Procedures Air Supply System Requirements NOTICE! 3.1.1 Pressure and Flow - Verify that the air supply system has capacity to supply your air hoist with required pressure and flow. Otherwise the hoist may operate poorly or may fail to operate. Section 3.2.

  • Page 20: Air Dryer

    Air Dryer – CAUTION! To prevent corrosion and hoist malfunction, employ an air dryer in the air supply system to ensure that dry air is supplied to the hoist. If there is moisture in the air supplied to the hoist, this moisture will cause corrosion on internal hoist components during periods when the hoist is idle leading to hoist malfunction.
  • Page 21 NOTICE! 3.6.2 Piping - Pipe should be sized to accommodate the hoist airflow requirements. Table 3-1 gives recommended pipe sizes. Table 3-1 Air Supply Pipe and Hose Sizes Diameter of Supply Diameter of Supply Model Pipe Hose TCR250P, 250C, 500P, 500C, 1000P, 1000C Inside diameter Inside diameter TCR1000P2, 1000C2, 2000P2, 2000C2...

  • Page 22: Mounting Location

    Mounting Location CAUTION! 3.7.1 Prior to mounting the hoist ensure that the suspension and it supporting structure are adequate to support the hoist and its loads. If necessary consult a professional that is qualified to evaluate the adequacy of the suspension location and its supporting structure. NOTICE! 3.7.2 Section 7.6...

  • Page 23: Optional Chain Container

    3.10 Optional Chain Container 3.10.1 For installation of the optional bag style chain container refer to Figure 3-5 below and perform the following:  Make sure all end stoppers and limit locks are installed correctly. See Sections 3.12 and 7.3. ...

  • Page 24: Non-Stationary Application

    Method of Setting The Chain Basket For TCR250  Put the basket arm into the housing front and fix them securely with the arm holder using bolts and nuts as it is shown below.  Set the chain basket on the basket arm as it is shown below. 3.11 Non-Stationary Application 3.11.1 For applications such as rental fleets or construction sites where the hoist is moved from place-to-...

  • Page 25: Preoperational Checks And Trial Operation

    3.12 Preoperational Checks and Trial Operation CAUTION! 3.12.1 Check for the availability of required operating air pressure of between 60 PSI to 90 PSI at the hoist's inlet port before trying to operate the hoist. WARNING! 3.12.2 Verify that the load chain is not twisted or tangled and that the bottom hook is not capsized prior to operating the hoist.
  • Page 26 WARNING! 3.12.3 Confirm the adequacy of the rated capacity for all slings, chains, wire ropes and all other lifting attachments before use. Inspect all load suspension members for damage prior to use and replace or repair all damaged parts. WARNING! 3.12.4 For Models TCR500P&C, 1000P2&C2, 1000P&C and 2000P2&C2 verify the limit locks are properly installed on the load chain.
  • Page 27 3.12.7 Ensure that the hoist is properly installed to either a fixed point, or trolley, whichever applies. 3.12.8 If hoist is installed on a trolley, ensure that  trolley is properly installed on the beam, and  stops for the trolley are correctly positioned and securely installed on the beam. 3.12.9 Ensure that all nuts, bolts and split (cotter) pins are sufficiently fastened.

  • Page 28: Operation

    Operation Introduction DANGER! DO NOT WALK UNDER A SUSPENDED LOAD WARNING! HOIST OPERATORS SHALL BE REQUIRED TO READ THE OPERATION SECTION OF THIS MANUAL, THE WARNINGS CONTAINED IN THIS MANUAL, INSTRUCTION AND WARNING LABELS ON THE HOIST OR LIFTING SYSTEM, AND THE OPERATION SECTIONS OF ANSI/ASME B30.16 and ANSI/ASME B30.10. THE OPERATOR SHALL ALSO BE REQUIRED TO BE FAMILIAR WITH THE HOIST AND HOIST CONTROLS BEFORE BEING AUTHORIZED TO OPERATE THE HOIST OR LIFTING SYSTEM.

  • Page 29: Shall's And Shall Not's For Operation

    The operation of an overhead hoist involves more than activating the hoist’s controls. Per the ANSI/ASME B30 standards, the use of an overhead hoist is subject to certain hazards that cannot be mitigated by engineered features, but only by the exercise of intelligence, care, common sense, and experience in anticipating the effects and results of activating the hoist’s controls.
  • Page 30 CAUTION! Improper operation of a hoist can create a potentially hazardous situation which, if not avoided, could result in minor or moderate injury, or property damage. To avoid such a potentially hazardous situation THE OPERATOR SHALL: • • Use the hoist manufacturer’s recommended parts Maintain a firm footing or be otherwise secured when operating the hoist.

  • Page 31: Hoist Controls

    Hoist Controls 4.3.1 Pendant Control - When using the pendant control depress the up lever to raise the hoist or the down lever to lower the hoist as shown in Figure 4-1 below. To stop motion release the lever switches. Figure 4-1 Pendant Control 4.3.2...

  • Page 32: Operation Of The Load Limiter

    4.4.2 For the cord type control, adjust the speed by varying the amount of pull on the cord. Refer to Figure 4-3. Figure 4-3 Cord Control Speed Adjustment Operation of the Load Limiter 4.5.1 If a hoist is used to lift a load that exceeds the hoists rated capacity, the load limiter will cause the hoist to automatically stop lifting.

  • Page 33: Inspection

    Inspection General 5.1.1 The inspection procedure herein is based on ANSI/ASME B30.16. The following definitions are from ANSI/ASME B30.16 and pertain to the inspection procedure below.  Designated Person - a person selected or assigned as being competent to perform the specific duties to which he/she is assigned.

  • Page 34: Frequent Inspection

    Frequent Inspection 5-1, “Frequent 5.3.1 Inspections should be made on a FREQUENT basis in accordance with Table Inspection.” Included in these FREQUENT Inspections are observations made during operation for any defects or damage that might appear between Periodic Inspections. Evaluation and resolution of the results of FREQUENT Inspections shall be made by a designated person such that the hoist is maintained in safe working condition.

  • Page 35: Occasionally Used Hoists

    Occasionally Used Hoists 5.5.1 Hoists that are used infrequently shall be inspected as follows prior to placing in service:  Hoist Idle More Than 1 Month, Less Than 1 Year: Inspect per FREQUENT Inspection criteria of Section 5.3 above.  Hoist Idle More Than 1 Year: Inspect per PERIODIC Inspection criteria of Section 5.4 above.
  • Page 36 Table 5-3 Hoist Inspection Methods and Criteria Item Method Criteria Action Hooks - Bent Shank Visual Shank and neck portions of hook should be free Replace. or Neck of deformations Hooks - Yoke Visual Should be free of significant rust, weld splatter, Clean/Lubricate, or Assembly nicks, gouges.
  • Page 37 Table 5-3 Hoist Inspection Methods and Criteria Item Method Criteria Action Bolts, Nuts and Visual, Check Bolts, nuts and rivets should not be loose. Tighten or replace Rivets with Proper Tool as required. Housing and Visual, Auditory, Hoist components including load blocks, Replace Mechanical Vibration,...
  • Page 38 Table 5-4 Brake Disc Dimension Std Dimension Minimum Value for Replacement Hoists Inch (mm) Inch (mm) TCR250 T = 0.31 (8.0) T = 0.29 (7.3) TCR500, 1000-2 T = 0.31 (8.0) T = 0.29 (7.3) TCR1000, 2000-2 T = 0.31 (8.0) T = 0.29 (7.3) TCR3000, 6000-2 T = 0.31 (8.0)
  • Page 39 Table 5-6 Top Hook & Bottom Hook Dimensions Dimensions K and U should be measured and recorded below prior to any use when the hook is first placed into service. Maximum/Minimum Value Hoists Recorded Dimension When New for Replacement Top Hook K = _______________ Top Hook U = _______________ TCR250 Bottom Hook K = ____________...

  • Page 40: Lubrication

    Lubrication Air Hoist Lubrication 6.1.1 See Section 3.0 for lubrication requirements. CAUTION! 6.1.2 Lubrication to the motor will be provided primarily by the air supply lubricator. The recommended amount is 10-15 drops/minute (2-3cc/min.). Refer to Table 6-1 below for the approved lubricant for use with your air hoist.

  • Page 41: Maintenance & Handling

    Maintenance and Handling Load Limiter 7.1.1 The purpose of the load limiter is to prevent using the hoist in an overload situation. When lifting, the hoist will stop automatically if the load is above the rated capacity of the hoist. 7.1.2 The adjustment is factory set to actuate at approximately125% of rated capacity (based on supply air pressure of 90 PSI).

  • Page 42: Brake

    Refer to Figure 7-1. Loosen the lock nut and slowly turn the adjustment screw OUT until it is loose and no longer is in contact with the internal load limiter spring – as this occurs the screw should become easier to turn. Stop turning the screw once it is loose and easier to turn. Turn the adjustment screw IN just enough so that it begins to contact the internal load limiter spring –...

  • Page 43: Load Chain

    An air supply line must be connected to the hoist in order to perform the following procedures. WARNING! Be certain that the replacement chain is obtained from Kito and is the exact size, grade and construction as the original chain. CAUTION! When replacing load chain, check for wear on mating parts, i.e.
  • Page 44 CAUTION! Invert the hoist such that the chain separator openings are facing up. The chain must be inserted into the chain separator on the no load side opening. This is where the no load end of chain attaches to hoist body. Without inserting the load chain, operate the hoist pendant or cord control to determine which direction the load sheave is rotating in relation to the pendant control function pressed or pulled.
  • Page 45 WARNING! Make sure end stoppers and limit locks are installed in accordance with Table 7-1 and the diagram in Figure 7-4. Ensure that chain remains free of twists when attaching dead end(s) of chain and when feeding chain through bottom hook case (double fall units). Refer to Figures 3-6 and 3-7.

  • Page 46: Load Sheave

    Load Sheave Inspection 7.5.1 Perform this inspection by removing the chain separator and viewing the load sheave while operating “Operation”. Refer to the hoist slowly, with no load, and in accordance with Section 4 Figure 7-8 remove the chain separator as follows. ...

  • Page 47: Pendant

    Pendant 7.3.1 The following procedure covers the installation of a pendant control station. 1) Put 3 red tubes and wire through the bracket hole. See Figure 7-6. 2) Attach the hoses to the bracket by installing the retaining nut to the fitting. 3) Torque retaining nut to 20 lbf.-ft.

  • Page 48: Storage

    Figure 7-9 Hose Pendant Connections For TCR250P Storage 7.4.1 Whenever the hoist is to be placed into storage, place extra lubricating oil into the air inlet opening and circulate the air motor before plugging the inlet. Make certain that no debris, dirt or moisture is allowed to enter the air hoist through air inlet opening during preparations for storage.

  • Page 49: Troubleshooting

    Troubleshooting WARNING! HAZARDOUS AIR PRESSURE IS PRESENT IN THE HOIST, IN THE SUPPLY OF COMPRESSED AIR TO THE HOIST, AND IN CONNECTIONS BETWEEN COMPONENTS. Before performing ANY maintenance on the equipment, de-energize the supply of compressed air to the equipment, and lock and tag the supply device in the de-energized position. Refer to ANSI Z244.1, “Personnel Protection - Lockout/Tagout of Energy Sources.”...
  • Page 50 Table 8-1 Troubleshooting Guide Symptom Cause Remedy Air leak between the two chambers Lifting speed is slow Correct or repair to eliminate air leak. in the Top Cover Lack of air pressure or loss of air Repair or adjust air supply or filters. supply.
  • Page 51 Kito Air Hoists Parts List...

  • Page 52: 9.0 Parts List

    TCR250 MAIN BODY 9.0 Parts List TCR250 Main Body...
  • Page 53 TCR250 MAIN BODY Parts Parts Figure # Name Part # Figure # Name Part # Hoist Hoist Motor Case T1CR426205790 Lock Screw T1CR426205890 Rear Plate T1CR426205180 Brake Plate T1CR426205900 Cylinder T1CR426205160 Bearing T1CR130112806 Rotor T1CR426205150 Bearing T1CR130113003 Front Plate T1CR426205170 Needle Bearing T1CR130170013 Vane...
  • Page 54 TCR250 VALVE BODY TCR250 Valve Body...
  • Page 55 TCR250 VALVE BODY Cord Model Only: Parts Figure # Name Part # Parts Hoist Figure # Name Part # Hoist Main Spool T1CR426205010 Valve Bushing T1CR426205780 Valve Body T1CR426205061 Shuttle T1CR426205870 Valve Spring T1CR130802208 Valve Seat R T1CR426205830 Hex Socket Pipe Plug T1CR134902003 Valve Seat L T1CR426205840...
  • Page 56 TCR250 MANIPULATOR CONTROL TCR250M Manipulator Control...
  • Page 57 TCR250 MANIPULATOR CONTROL Parts Parts Figure # Name Part # Figure # Name Part # Hoist Hoist Chain Basket CP T1CR42621592C Shield T1CR426215B20 Bucket Arm Assembly (pair) 1 pr. T1CR426205920 Hex Socket Pipe Plug T1CR134901006 Arm Holder T1CR426205820 Manipulator Warning Tag T1CR137304071 Bolt T1CR131605016...
  • Page 58 TCR500 MAIN BODY...
  • Page 59 Figure Parts Figure Parts Figure Parts Part # Part # Part # Part Name Part Name Part Name Hoist Hoist Hoist T1CR130406005 PARALLEL PIN T1CR131103002 O-RING 115D T1CR131705035 SOCKET BOLT T1CR426224151 ROTOR T1CR131101004 O-RING 115E T1CR134501005 U-NUT T1CR426224161 STATOR T1CR131103055 O-RING CHAIN SPRING T1CR130802219 T1CR426224171 FRONT PLATE...
  • Page 60 TCR1000-2 Main Body...
  • Page 61 Parts Parts Figure Figure Parts Part Name Part Name Part # Part # Figure Part Name Part # Hoist Hoist Hoist T1CR130406005 PARALLEL PIN T1CR131103055 O-RING 115H T1CR426244580 CHAIN PIN T1CR426224151 ROTOR T1CR131706012 SOCKET BOLT 115J T1CR131307006 WASHER T1CR426224161 STATOR T1CR131706040 SOCKET BOLT 115K T1CR134501006...
  • Page 62 TCR1000 Main Body...
  • Page 63 Parts Parts Parts Figure Figure Figure Part Name Part Name Part Name Part # Part # Part # Hoist Hoist Hoist T1CR130406005 PARALLEL PIN T1CR131101004 O-RING T1CR426266390 END STOPPER T1CR426224151 ROTOR T1CR131103055 O-RING T1CR426261S2C BOTTOM HOOK SET T1CR426224161 STATOR 120A T1CR426221S2F BOTTOM HOOK ASSY.
  • Page 64 TCR2000-2 Main Body...
  • Page 65 Parts Parts Parts Figure Figure Figure Part Name Part Name Part Name Part # Part # Part # Hoist Hoist Hoist T1CR130406005 PARALLEL PIN T1CR131103055 O-RING 115AE T1CR134501004 U-NUT T1CR426224151 ROTOR T1CR131706012 SOCKET BOLT 115B T1CR426286570 TOP YOKE ASSY. T1CR426224161 STATOR T1CR131706040 SOCKET BOLT 115C...
  • Page 66 TCR3000 Main Body...
  • Page 67 Parts Parts Parts Figure Figure Figure Part Name Part Name Part Name Part # Part # Part # Hoist Hoist Hoist T1CR130406005 PARALLEL PIN T1CR130802213 DISC SPRING T1CR42632557F TOP HOOK SET T1CR426325150 ROTOR T1CR131103008 O-RING 115AB T1CR420655P11 HOOK LATCH T1CR426325160 STATOR T1CR131101004 O-RING 115AC...
  • Page 68 TCR6000-2 Main Body...
  • Page 69 Parts Parts Figure Figure Parts Part Name Part Name Part # Part # Figure Part Name Part # Hoist Hoist Hoist T1CR130406005 PARALLEL PIN T1CR130802213 DISC SPRING T1CR42633569G TOP HOOK SET T1CR426325150 ROTOR T1CR131103008 O-RING 115A T1CR420890PAF TOP HOOK ASSY. T1CR426325160 STATOR T1CR131101004 O-RING 115B...
  • Page 70 Cord Control Valve Body...
  • Page 71 Part Number Part Number Parts Parts TCR500C TCR500C Figure Figure Part Name Part Name TCR1000C2 TCR3000C TCR1000C2 TCR3000C Hoist Hoist TCR1000C TCR6000C2 TCR1000C TCR6000C2 TCR2000C2 TCR2000C2 T1CR426325740 CAM T1CR426224063 VALVE BODY T1CR426224110 T1CR426325113 CHAIN LEVER T1CR426224070 TOP COVER T1CR426224083 SIDE COVER (L) T1CR426224120 ROLLER SHAFT T1CR426224093...
  • Page 72 Pendant Control Valve Body...
  • Page 73 Part # Part # Parts Parts TCR500P TCR500P Figure Figure Part Name Part Name TCR1000P2 TCR3000P TCR1000P2 TCR3000P Hoist Hoist TCR1000P TCR6000P2 TCR1000P TCR6000P2 TCR2000P2 TCR2000P2 T1CR426325740 CAM T1CR426224083 SIDE COVER (L) T1CR426224093 SIDE COVER (R) T1CR426224110 T1CR426325113 CHAIN LEVER T1CR426224101 LIMIT GUIDE T1CR426224120...
  • Page 74 Parts Figure Part Number Part Name Number Handle T1CR420226VRD PENDANT VALVE ASSEMBLY T1CR420218VB0 THROTTLE VALVE T1CR420226VR0 VALVE BODY T1CR420218VF0 BUSHING T1CR130402071 LEVER PIN T1CR420218VH0 LEVER T1CR130802220 SPRING 6X14X0.6 T1CR132106006 SET SCREW M6X6 T1CR131109001 O-RING S-3 (HS90) T1CR131103008 O-RING S-10 T1CR131103009 O-RING S-11.2 T1CR135106302 HOSE JOINT H-2 PT 1/8-7...
  • Page 75 Parts Figure Part Name Part # Hoist T1CR132506012 SLOTTED HEAD MACHINE SCREW T1CR42622452D PENDANT HANDLE CP T1CR426221E20 HOSE NIPPLE T1CR137240020 PENDANT HOSE ASSEMBLY T1CR136102094 SEAL WASHER 160A T1CR426224520 CONTROL HANDLE 160B T1CR130501004 STEEL BALL 160C T1CR130802255 PENDANT VALVE SPRING 160D T1CR426221H30 PENDANT VALVE SEAT 160E T1CR131103008...
  • Page 76 Model Part Number Quantity per Hoist TCR250P T1CR426206D5D TCR500P T1CR426224D5D TCR1000P2 T1CR426224D5D TCR1000P T1CR426266D5D TCR2000P2 T1CR426266D5D TCR3000P T1CR426325D5D TCR6000P2 T1CR426325D5D TCR250C T1CR426205D5D T1CR426224D5D TCR500C T1CR426224D5D TCR1000C2 TCR1000C T1CR426266D5D TCR2000C2 T1CR426266D5D Tune-up kit contains all: gaskets, o-rings, silencer, motor vanes and springs TCR3000C T1CR426325D5D TCR6000C2...

  • Page 77: 10.0 Warranty

    10.0 Warranty All products sold by Kito Canada Inc. are warranted to be free from defects in material and workmanship for the given period of that product, from the date of purchase. The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, unauthorized repairs or alterations.
  • Page 78 Kito Canada Inc. West Kito Canada Inc. East 309-3815 1 Avenue 6-1750 Courtney Park Drive E. Burnaby, BC V5C 3V6 Mississauga, ON L5T 1W1 Phone: 604-291-9955 Phone: 905-405-0905 Toll Free: 1-888-322-KITO Toll Free: 1-888-322-KITO Fax: 604-294-8855 Fax: 905-405-0906 www.kito.ca...
