Configure the G.703 Interface (Optional)

1. Enter interface e1 1/2 to activate the interface configuration mode for the DSX-1 interface.
2. Enter multiframe ts16 to verify the G.703 interface is configured for voice signaling (timeslot
16 used for signaling).
3. Enter no shutdown to activate the G.703 interface.
4. Enter exit to return to the Global Configuration mode.

Configure the Frame Relay Virtual Interface

The following steps outline configuring a Frame Relay virtual interface (labeled 1) using a single
DLCI back to the corporate router (defined as DLCI 16).
1. At the (config)# prompt, enter interface fr 1 to create a Frame Relay virtual interface
labeled 1.
2. If the default setting of ansi was changed, enter frame-relay lmi-type ansi to configure
Frame Relay virtual interface 1 to use ANSI (Annex D) signaling.
3. Enter no shutdown to activate the virtual interface to pass data.
4. Enter exit to return to the Global Configuration mode.
5. The unit has a factory default PPP 1 interface. Enter the command no ppp 1 to remove this
interface.

Create the PVC and Assign an IP Address

1. At the (config)# prompt, enter interface fr 1.16 to create a PVC assigned to Frame Relay
virtual interface 1. This activates the configuration parameters for the PVC. Your prompt
should now display (config-fr 1.16)#.
2. Enter frame-relay interface-dlci 16 to assign DLCI 16 to this PVC.
3. Enter ip address 192.168.72.1 255.255.255.252 to assign an IP address of 192.168.72.1 for
this PVC using a 30-bit subnet mask.
4. Enter no shutdown to activate the virtual interface to pass data.
5. Enter exit to return to the Global Configuration mode.
6. If you are configuring the NetVanta for use in a Frame Relay application and have completed
this step, skip to Create the Cross-Connect on page 5.
The default encapsulation is RFC 1490 or IETF. Make certain the remote unit uses the
same encapsulation for Frame Relay.
4 Technical Support +1-256-963-8716
on page 5 for PPP configuration.
64200868L1-42C
