Extech Instruments MultiLog ML720 User Manual page 5

AC CURRENT
RANGE
50 / 60Hz
500.0µA, 5000µA
50.00mA, 500.0mA
5.000A, 10.00A*
40Hz to 1kHz
500.0µA, 5000µA
50.00mA
500.0mA
5.000A, 10.00A*
*10A continuous, 20A for 30-second max with 5 minute cool down interval
TEMPERATURE
RANGE
-50°C TO 1000°C
-58°F TO 1832°F
RESISTANCE
RANGE
50.00Ω
500.0Ω
5.000kΩ, 50.00kΩ, 500.0kΩ
5.000MΩ
50.00MΩ
Open Circuit Voltage: < 1.3VDC (< 3VDC for 50Ω & 500Ω ranges)
CAPACITANCE
RANGE
50.00nF, 500.0nF
5.000µF
50.00µF
500.0µF
9999µF
*Accuracies with film capacitor or better
Accuracy
0.6%+3d
0.6%+3d
0.6%+3d
0.8%+4d
0.8%+4d
1.0%+4d
0.8%+4d
Accuracy
0.3% + 3d
0.3% + 6d
Accuracy
0.2% + 6d
0.1% + 3d
0.1% + 2d
0.4% + 3d
1.5% + 5d
Accuracy*
0.8% + 3d
1.0% + 3d
2.0% + 3d
3.5% + 5d
5.0% + 5d
Burden Voltage
0.15mV/µA
3.3mV/mA
0.03V/A
0.15mV/µA
3.3mV/mA
3.3mV/mA
0.03V/A
5
