ANTENNAS, CABLES, GPS
Category
Typical Radiated Gain
Radiation
Polarization

Antenna Cable Information

Use the following UFL to SMA RF cable to connect the device to the antenna.
Description:
Multi-Tech Part Number:
Multi-Tech ordering information:
Model
CASMA-UFL-1
CASMA-UFL-10
CASMA-UFL-50
Average Cable Loss
The table shows the average cable loss for each cell band.
Band
800
1900

GPS Antenna Specifications

Manufacturer:
Description:
Model Number:
Multi-Tech Part Number:
MultiTech Ordering Information
Model
ANGPS-1MM
ANGPS-10MM
ANGPS-50MM
42
Description
2 dBi on azimuth plane
Omni-directional
Linear vertical
Coax SMA to UFL 8.5inch (216mm)
45009575L
Quantity
1
10
50
Loss
0.37
0.63
Trimble
GPS Antenna with low noise amplifier
66800-52
45009665L
Quantity
1
10
50
®
