Developer Kit Contents

Your Developer Kit (MTPCIE-DK1) includes the following:
Developer Board
Power Supply
Cables
Antennas
Customer Notices
Additional
®
MultiConnect PCIe MTPCIE-EV3 Developer Guide
1 - MTPCIE-DK1 Developer Board
1 - 100-240V 9V-1.7A power supply with removable blades, 1 - US blade/plug, 1 - EURO
blade/plug, 1 - UK blade/plug
1 - RS-232 DE9F-DE9M serial cable, 1 - RJ-45 Ethernet cable, 2 -USB cable 2 - SMA-to-UFL
antenna cables (1 - for cellular, 1 - for GPS) 1 - RSMA-to-UFL antenna cable for
Bluetooth/Wi-Fi.
Note: For MTPCIE-EV3 models, your final product design needs to have approved
Exceltek antenna. For details, refer to Antennas, Cables, and GPS. Also note that
the Bluetooth/WiFi antenna is included in the Developer Kit for use other models;
MTPCIE-EV3 does not include Bluetooth/WiFi.
1 - 3.3V magnetic GPS antenna , 1 - HEPTA band SMA antenna, 1 - 2.4GHz, dipole Wi-Fi
antenna
Legal and Support information
One promotional screwdriver
