PINOUT

Standard Mini-PCI Express Pinout

For reference only.
Pin # Function
1 WAKE#
2 3.3Vaux
3 COEX1
4 GND
5 COEX2
6 1.5V
7 CLKREQ#
8 UIM_PWR
9 GND
10 UIM_DATA
11 REFCLK+
12 UIM_CLK
13 REFCLK-
14 UIM_RESET
15 GND
16 UIM_VPP
17 Reserved
18 GND
19 Reserved
20 W_DISABLE#
21 GND
22 PERST#
23 PERn0
24 3.3Vaux
25 PERp0
26 GND
27 GND
28 1.5V
29 GND
30 SMB_CLK
31 PETn0
10
I/O Description
O WAKE
I 3.3Vaux
I Co-existence pin, not defined
GND
I Co-existence pin, not defined
I 1.5V
O CLKREQ#
I UIM_PWR
GND
I/O UIM_DATA
I PCI Express reference clock
I UIM_CLK
I PCI Express reference clock
I UIM_RESET
GND
0 UIM_VPP
Reserved
GND
Reserved
I W_DISABLE#
GND
I PERST#
O PCI Express receiver differential pair signal
I 3.3Vaux
O PCI Express receiver differential pair signal
GND
GND
I 1.5V
GND
I SMB_CLK
I PCI Express transmitter differential pair signal
