Antenna Specifications
Category
Frequency Range
Impedance
VSWR
Gain
LNA Current Consumption
Noise Figure
Polarization
Input voltage

OEM Integration

FCC and Industry Canada Information to End-users
FCC & IC Information to End-users The user manual for the end-users must contain the statements required by the
following FCC and IC regulations: 47 C.F.R. 15.19(a)(3), 15.21, 15.105 and RSS-Gen Issue 3, Dec 2010; 7.1.2 and
7.1.3
FCC Grant Notes
The OEM should follow all the grant notes listed below. Otherwise, further testing and device approvals may be
necessary.
Installing in Portable Equipment
The available scientific evidence does not show that any health problems are associated with using low power
wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power
wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas
high levels of RF can produce health effects (by heating tissue), exposure of low-level RF that does not produce
heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not found
any biological effects. Some studies have suggested that some biological effects might occur, but such findings
have not been confirmed by additional research.has been tested and found to comply with FCC radiation exposure
limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in
Supplement C to OET65.
FCC Definitions
Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used so that the
radiating structure(s) of the device is/are within 20 centimeters of the body of the user.
Mobile: (§2.1091) — A mobile device is defined as a transmitting device designed to be used in other than fixed
locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally
maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons.
Grant Limitations
This device is a mobile device with respect to RF exposure compliance. The antenna(s) used for this transmitter
must be installed to provide a separation distance of at least 20 cm from all persons, and must not be collocated or
operate in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter
®
MultiConnect PCIe MTPCIE-EV3 Developer Guide
Description
1575.24 MHz
50 Ohms
2.0:1 max
10-30 dBi
40 mA max
< 2dB
RHCP
3.0V M M 0.2V
