Jumper
JP88
JP89
JP90
J6
J23
J8, J9, J10, J13
S1
S3
S4
®
MultiConnect
PCIe MTPCIE-EV3 Developer Guide
Description
May be used to manually reset PCIe Wi-Fi device by briefly installing and then
removing a jumper. Default is no jumper installed.
This jumper, when installed, connects power to PCIe device.
Not used by PCIe device.This jumper, when installed, connects power to OCG-E
device. (When using Developer Kit with OCG-E devices).
Not used by PCIe device.
Socket for installing PCIe device.
Oscilloscope probe ground connections
Not used by PCIe device.
Reset button for PCIe device.
Button for on/off of PCIe.
BOARD COMPONENTS
29
