Summary of Contents for WANHAO Duplicator i3
- Page 1 WANHAO PRINTER Catalogue Duplicator Three Duplicator 3 First Run Experience Tel: +86-579-82346658 Email: Support@wanhao3dprinter.com Web: WWW.WANHAO3DPRINTER.COM...
- Page 2 The Duplicator 3 First Run Experience The Duplicator 3 First Run Experience The Duplicator 3 First Run Experience The Duplicator 3 First Run Experience Safety Information Safety Information Safety Information Safety Information 1.1 Caution Caution Caution Caution: The Duplicator 3 generates high temperatures and includes moving parts that can cause injury. Never reach inside the Duplicator 3 while it is in operation, and allow time for the Duplicator 3 to cool down after operation.
- Page 3 If everything is ready, then flip on the power button on the back of your Duplicator 3 and hold onto your hat. Not literally, though -- if this causes a large gust of wind, you should probably contact tech support at support@wanhao3dprinter.com .
- Page 4 Follow the on-screen instructions to set up your Duplicator 3 for the first time! And remember, if anything goes wrong, or things aren't happening the way this guide says they should, check out the Troubleshooting page or get in touch with Support. Leveling Your Platform Leveling Your Platform Leveling Your Platform...
- Page 5 These four knobs are the ones on the bottom of the platform, just inside the plastic arms that hold it up. 3.4 It's actually easier to level the platform if you don't tighten these all the way. Instead, tighten each knob four complete turns.
- Page 6 At each stage of the script, your Duplicator 3 will ask you to test the platform height by sliding a piece of paper between the platform and nozzle. Your Accessory Box included a business card from Wanhao Support. It's about .12 mm thick, and should work great. If you haven't got the Support card on hand, a sticky note works well, too.
- Page 7 4.2 Make sure to hold down the Blue ring that connects the tube to the Stepstruder-- just pulling on the tube won’t work.
- Page 8 Once the tubes are disconnected, you can go ahead and feed the filament into the guide tubes from the back until you see it come out at the front. 4.4 Make sure that the filament loads up from the center on both spools, so you don't get jams during printing.
- Page 9 You’ll have to wait for a few minutes for them to heat up. Be careful not to touch the bottom of the Step exstruder while it’s heating -- it gets up to about 220° C, which is hot and can burn you! 4.6 - 4.7 Once the nozzle is at temperature, The Duplicator 3 will tell you to load filament in the right-hand Step exstruder.
- Page 10 Click through the message until your Duplicator 3 asks you to press the Middle Blue Middle Blue Middle Blue Middle Blue when you see plastic extruding. Then take the end of the filament itself and Button Button Button Button push it right into the center of the gray ring. Make sure it goes into the center, and doesn’t get caught at the edge.
- Page 11 You'll have to use to use some force, but as long as you’re holding only the filament, you can’t hurt your Duplicator 3. Maintain pressure on the filament, and after a few moments you should feel the motor pulling it in. Then you’ll see some plastic start to come out the nozzle. When that happens, you can press the and push the guide tubes back Middle Blue Button...
- Page 12 Make sure your SD card is in the SD card slot at the right side of The Duplicator 3. Then, if you’ve successfully leveled your platform and loaded filament into your extruder, answer yes! The Duplicator 3 will drop you into the “Print from SD”...
