1/10 ep rwd competition r/c drift car chassis kit (32 pages)
Summary of Contents for Yokomo YZ-4
Page 2
走行してして下さい。 ① スピー ドコン トローラのスイッチをOFFにします。 ② バッテリーの接続を外します。 ③ 送信機のスイッチをOFFにし、 アンテナを縮めます。 Thank you for purchasing this Yokomo product. This high performance competition kit has been proudly manufactured by Yokomo - World Champion R/C car manufacturer. Proper assembly of this product will provide fun, safe enjoyment. PRECAUTIONS FOR SAFE ENJOYMENT OF YOUR R/C CAR For children under the age of 13, parental guidance is recommended when running. ■ ASSEMBLY PRECAUTIONS ■ ■ PRECAUTIONS BEFORE RUNNING ■ ■ BATTERY USAGE ■ ● Do not assemble around small children. The ● Yokomo R/C cars are built for competition use, and (Carefully read the instruction included with the batteries) parts can be dangerous if accidentally some models may exceed speeds of 40km per hour. ● When charging batteries, make sure that the swallowed. Practice common sense and run the car in open safe surrounding area is void of anything highly flammable. places, or R/C car tracks. ● Check the contents carefully before Also avoid charging in high-temperature locations. assembly. Please contact Customer Support ● Do not run the car on public roads with high amounts ...
Page 3
組立てに必要な物 ACCESSORIES AND TOOLS NEEDED FOR KIT ASSEMBLY 走行のために別途お買い求め頂くもの ADDITIONAL ITEMS REQUIRED FOR USE (NOT INCLUDED IN KIT) 2 チャンネルプロポ (1 サーボ、1 アンプ仕様 ) TWO CHANNEL R/C SURFACE RADIO SYSTEM AND ELECTRONIC SPEED CONTROL 走行用7.2Vバッテリーパック (ス トレー トパック/セパレー トタイプ) 7.2V BATTERY PACK (Straight Pack / Saddle Pack Type) 走行用バッテリー充電器 BATTERY CHARGER 走行用モーター MOTOR ボディ塗装用カラー BODY SPRAY PAINT 組み立ての際に別途用意する工具 ASSEMBLING TOOLS REQUIRED. (NOT INCLUDED IN KIT) ヘックス ドライバー (2㎜、 1.5㎜) プラス ドライバー (小) HEX WRENCH SCREW DRIVER(SMALL) Y T −15W ワークスレンチ 1.5mmヘックス ドライバー ¥ 1200 Y T −D P 1W ワークスレンチ # 1プラス ドライバー ¥ 1200 Y...
Page 4
1. メインシャシーの組立て Main Chassis Assembly Z4-002SP サイドプレート Side plate このページで使用するパーツ Parts used on this page Z4-002 メインシャシー ×1 Main Chassis 袋 #1 の内容 Bag #1 Contents Z4-201P ベルクランクポスト Bellcrank Post Z4-002 メインシャシー Main chassis Z4-002SP サイドプレート L&R 各 1 Side plate L & R 1Ea Z4-201P ベルクランクポスト ×2 Bellcrank Post ZC-F38 M3x8 サラビス FHS Screw ZC-F38 M3x8 サラキャップ ×10 FHS Screw 2. バッテリーポストの取付け Battery Post Installation このページで使用するパーツ...
Page 5
3. バッテリーガイドの取付け Battery Guide Installation ZC-BH36 M3x6 ボタンヘッド BHS Screw Z4-001 バッテリーガイドは取付け方向により、 バッテリーガイド A バッテリー搭載位置をお選びください。 Battery guide A Mount the battery guides according to how you wish to position your batteries. Z4-001 バッテリーガイド C Battery guide C Z4-001 バッテリーガイド B Battery guide B P.13 で使用します。 Used on P.13 P.15 で使用します。 Used on P.15 Z4-001 バンパー Bumper このページで使用するパーツ Parts used on this page 袋 #1 の内容 Bag #1 Contents ZC-F38 M3x8 サラビス...
4. ベルクランクの取付け ZC-BH312 Bell Crank Installation ZC-206SH M3x12 ボタンヘッド ロッドエンドボール SS BHS Screw Ball Stud SS 袋 #2 の内容 Bag #2 Contents Z4-200 センターリンク Center Link ZC-206LH Z4-200 Z4-200 ロッドエンドボール L センターリンク ×1 ベルクランク ×2 Ball Stud L ZC-A3610B Center Link Bellcrank 1mm アルミスペーサー・黒 Z4-201CLC 1mm Aluminum Spacer ・ Black センターリンクカラー Center Link Collar ZC-A3610B 1mm アルミスペーサー・黒 1mm Aluminum Spacer ・ Black ZC-206SH ZC-BH35 ロッドエンドボール...
Page 7
6. リヤサスアームの取付け 広い Rear Suspension Arm Installation Wide S-T3-S2 袋 #3 の内容 Z4-008RS4 Bag #3 Contents リヤロアサスアーム S4 R Rear Lower Suspension Arm S4 R L-T3-S2 グレーのパーツは使用しません。 Shaded parts are not used. Z4-300 リヤサスマウント R/S-T3-S2 Rear Suspension Mount R/S-T3-S2 ZC-A3610B 1mm アルミスペーサー・黒 ZC-A3610B 1mm Aluminum Spacer ・ Black Z4-008RS4 1mm アルミスペーサー・黒 リヤロアサスアーム S4 L&R 各 1 1mm Aluminum Spacer ・ Black Rear Lower Suspension Arm S4 L & R 1Ea B4-009B インナーサスアームピン Inner Sus. Arm Pin Z4-008RS4 リヤロアサスアーム S4 L Rear Lower Suspension Arm S4 L Z2-001B リヤバンパー ×1...
Page 8
8. リヤギヤボックスの組み立て Z4-302R リヤギヤボックスL Rear Gear Box Assembly Rear Gear Box L BB-105-2 5x10 ベアリング このページで使用するパーツ Bearing Parts used on this page Z4-303TA トップシャフト Z2-503I Top Shaft アイドラーギヤ Idler Gear Z4-300 リヤアッパーアームマウントスペーサー ×1 BB-105-2 Rear Upper Arm Mount Spacer 5x10 ベアリング Bearing 袋 #5 の内容 Z2-303I Bag #5 Contents アイドラーシャフト Idler Shaft ZC-BH315 M3x15 ボタンヘッド ギヤデフ Assy BHS Screw Gear Diff Assembly BB-1510 10x15 ベアリング Bearing Z4-302R リヤギヤボックス...
9. フロントギヤボックスの組み立て Front Gear Box Assembly Z4-302F フロントボックス R BB-105-2 Front Gear Box R 5x10 ベアリング Bearing Z4-303TA トップシャフト Z2-503I Top Shaft アイドラーギヤ Idler Gear BB-105-2 このページで使用するパーツ 5x10 ベアリング Parts used on this page Bearing ZC-BH310 Z2-303I M3x10 ボタンヘッド アイドラーシャフト BHS Screw Idler Shaft Z4-300 フロントアッパーアームマウントL&R 各 1 ギヤデフ Assy Front Upper Arm Mount L & R 1Ea Gear Diff Assembly ZR-BP スポンジテープ ×1 BB-1510 Foam Tape 10x15 ベアリング Bearing 袋...
Page 10
10. フロント&リヤドライブプーリーの取り付け Front & Rear Drive Pulley Installation ●FRONT● Z4-630 フロントプーリー Front Pulley Z4-630 フロントプーリーフランジ Front Pulley Frange Z4-630 クリッカースプリング Z4-630 Clicker Spring クリッカー Clicker 袋 #6 の内容 ZC-N3L Z4-630 Bag #6 Contents M3 ナイロンナット スプリングガイド Nylon Nut Spring guide このページで使用するパーツ スプリングガイドを一杯まで締め込むとフルタイム 4WD となります。 Parts used on this page クリッカーを効かせる際は、締め込んだ状態から 2 〜 2 回半転緩めた状態でご使用ください。 Fully tightening the spring guide will engage full-time 4wd. To engage the clicker, loosen it two to two and a half turns from fully tight. Z4-630 Z4-630 フロントプーリー ×1...
Page 11
11. モーターマウント、センターマウントの組み立て Motor Mount, Center Mount Assmebly 袋 #6 の内容 Bag #6 Contents ZC-S320 3mm シム このページで使用するパーツ モーターマウント Motor Mount Parts used on this page BB-730-4 3x7 ベアリング Bearing モーターマウント ×1 ZC-F312 Motor Mount M3x12 サラビス BB-85-4 FH Screw 5x8 ベアリング Bearing ZC-F36 ZC-S520 Z4-CTP M3x6 サラキャップ φ5 ㎜ ×φ7 ㎜シム センターマウント L ×1 テンショナーポスト ×1 FHS Screw Shim Center Mount L Tensioner post ZC-N3P...
Page 12
13. メインドライブユニットの取り付け Main Drive Unit Installation Z4-291-6 フロントベルト ( 細 ) Front Belt (Narrow) メインドライブプーリー Assy Main Drive Pulley Assembly BB-105-2 5x10 ベアリング Bearing BB-105-2 5x10 ベアリング モーターマウント Assy Bearing Motor Mount Assembly センターマウント Assy ZS-011NM Center Mount Assembly ① Z4-630CR ドライブピン センタープーリーフランジ Drive Pin Center Pulley Frange Z4-630CR プーリー・ワイド Pulley・Wide ② 袋 #6 の内容 Bag #6 Contents ZC-N3L ZC-S36 M3 ナイロンナット ワッシャー...
Page 13
14. アッパーデッキの取り付け Upper deckt Installation ZC-BH38 M3x8 ボタンヘッド BHS Screw ZC-S320 ZC-N3L 3mm シム M3 ナイロンナット Nylon Nut BB-730-4 3x7 ベアリング Bearing ZC-BH320 M3x20 ナベビス ※ケーブルホルダーは袋 #1 に入っています。 BH Screw The cable holder are included in bag #1. ZC-A3610B 1mm アルミスペーサー・黒 Aluminum Spacer ・ Black このページで使用するパーツ Parts used on this page ZC-BH325 M3x25 ナベビス BH Screw 袋 #7 の内容 Bag #7 Contents Z4-001 M2x6 タッピングビス BH Tapping Screw BB-730-4 3x7 ベアリング...
Page 14
15. フロントハブキャリアの組み立て ZC-206LH Front Hub Carrier Assembly ロッドエンドボール L Ball Stud L ZC-BH38 ZC-A3610B M3x8 ボタンヘッド 1mm アルミスペーサー・黒 BHS Screw 1mm Aluminum Spacer ・ Black Z4-415A ステアリングプレート ZC-N3P Steering Plate Z4-01079 M3 ナット ユニバーサルドライブシャフト・フロント Universal Driveshaft・Front BB-105-2 5x10 ベアリング BM-010BC Bearing このページで使用するパーツ フロント ベアリングカラー・青 Front Bearing Collar・Blue Parts used on this page Z4-415S ステアリングブロックL 袋 #8 の内容 Steering Block L BB-105-2 Bag #8 Contents 5x10 ベアリング...
Page 15
16. フロントサスアームの取り付け Front Suspension Arm Installation Z4-008F フロントロアサスアーム Front Lower Suspension Arm BM-415C ハブキャリアスペーサー・透明 Hub Carrier Spacer ・ Clear B2-009AR B2-009AR M2x4 トラスタッピング アウターサスアームピン BH Tapping Screw Outer Suspension Arm Pin ◆右側も同様に組立てます。 ◆ Assemble the right side in the same manner. このページで使用するパーツ Parts used on this page Z4-300RU サスマウントインサート 0°×2 Suspension Mount Insert ② Z4-001 バンパー ×1 ① Bumper Z4-300RU サスマウントインサート 0° 袋 #9 の内容 Suspension Mount Insert ③ Bag #9 Contents B2-009BF ※サスマウントインサートは袋...
Page 16
17. リヤハブキャリアの組み立て Rear Hub Carrier Assmebly このページで使用するパーツ Parts used on this page Z2-010R ZC-206LH ユニバーサルドライブシャフト・リヤ ロッドエンドボール L Universal Driveshaft・Rear Ball Stud L 袋 #8 の内容 Bag #8 Contents ZC-A3610 1mm アルミスペーサー・黒 1mm Aluminum Spacer ・ Black B2-010R ユニバーサルドライブシャフト・リヤ ×2 Z2-415R Universal Driveshaft・Rear リヤハブキャリア 0° BB-105-2 Rear Hub Carrier 5x10 ベアリング Bearing 袋 #10 の内容 B2-010BC Bag #10 Contents リヤ ベアリングカラー・青 Rear Bearing Collar・Blue Z2-011S ホイルスペーサー 4.5・黒 BB-135-2 Wheel Spacer 4.5・Black 5x13 ベアリング...
Page 17
18. ターンバックルの組み立て Turnbuckle Assembly ●FRONT● BM-206 BM-TBL ロッドエンド フロント アッパーロッド ×2 (45 ㎜ターンバックル ) ターンバックルレンチ Ball Cup Front Upper Rod ×2 (45 ㎜ Turnbuckle) Turnbuckle Wrench 26 ㎜ ステアリングロッド ×2 (48 ㎜ターンバックル ) Steering Rod ×2 (48 ㎜ Turnbuckle) ターンバックル 29.5 ㎜ Turnbuckle 片方が逆ネジになっています。 One side is reverse threaded. BM-206 ロッドエンド Ball Cup ステアリングロッド Steering Rod フロント アッパーロッド Front Upper Rod ●REAR● リヤ アッパーロッド ×2 (52 ㎜ターンバックル ) Rear Upper Rod ×2 (52 ㎜...
Page 18
19. フロントショックタワーの取付け Front Shock Tower Installation ZC-BH322 M3x22 ボタンヘッド BHS Screw 袋 #12 の内容 Bag #12 Contents このページで使用するパーツ Z4-017 Parts used on this page フロントショックタワー Front Shock Tower ZC-N3P M3 ナット Z4-017 フロントショックタワー ×1 Front Shock Tower ZC-BH312 M3x12 ボタンヘッド ZC-BH312 ZC-N3P BHS Screw M3x12 ボタンヘッド ×4 M3 ナット ×2 BHS Screw ZC-BH322 M3x22 ボタンヘッド ×2 BHS Screw 20. リヤショックタワーの組み立て Rear Shock Tower Assembly 袋 #12 の内容 Bag #12 Contents ZC-BH322 ZC-N3P...
Page 19
21. リヤショックタワーの取付け Rear Shock Tower Installation ZC-BH38 M3x8 ボタンヘッド BHS Screw ① Z4-017 ショックタワースペーサー Shock Tower Spacer 袋 #12 の内容 Bag #12 Contents このページで使用するパーツ ② Parts used on this page ZC-BH325 M3x25 ボタンヘッド BHS Screw Z4-017 ショックタワースペーサー ×1 Shock Tower Spacer ZC-BH38 M3x8 ボタンヘッド ×2 BHS Screw ZC-BH325 M3x25 ナベビス ×4 六角レンチ(2.0mm) BH Screw Allen Key ( 2.0mm ) リヤタワーショックの取付け ( フロントマウントタイプ ) Rear Shock Installation (Front Mount Type) リヤショックはサスアームの前方、後方に装着可能です。 前方に装着する際は下記を参照ください。 ※フロントマウントタイプをお選びの際は、ボディ後方のカットラインは前寄りでカットしてください。 The rear shock can be mounted to the front or rear of the suspension arm. When mounting to the front-side, refer to the diagram shown below.
Page 20
22. フロント&リヤショックの組み立て Front & Rear Shock Assembly ◆フロント用、リヤ用各 2 セットを作ります。 ◆ Assemble 2 front and 2 rear shocks. YS-7A 袋 #13 の内容 O リング・ φ12 Bag #13 Contents O Ring このページで使用するパーツ Z2-S4S Parts used on this page フロントショックボディ Front Shock Body Z2-S4C X33 カラー・A ( 白 ) Collar・A (White) Z2-S4L Z2-S4S リヤショックボディ フロントショックボディ ×2 Z2-S3X Rear Shock Body Front Shock Body X33 X リング (クリア) X Ring ( Clear ) Z2-S4C X33 カラー・B ( 小...
Page 21
23. フロント&リヤショックの組み立てのつづき Front & Rear Shock Assembly ◆フロント用、リヤ用各 2 セットを作ります。 ◆ Assemble 2 front and 2 rear shocks. BM-S812R ショックオイル ショックキャップ Shock Oil オイルは溢れるギリギリ Shock Cap フロント/ #500 まで入れます。 リヤ/ #400 Fill to the rim with Front / #500 shock oil. Rear / #400 ショックオイルを入れ、ショック ショックキャップをしっかり シャフトをゆっくり動かして気泡を と締め込みます。 抜きます。 Securely tighten the Slowly move up and down to shock cap. remove air bubbles. ZC-C25 M2x5 キャップスクリュー ショック Assy SHC Screw Shock Assembly このページで使用するパーツ Parts used on this page ①...
Page 22
24. フロント&リヤショックの取り付け Front & Rear Shock Installation ●FRONT● ZC-N3L M3 ナイロンナット Nylon Nut Z2-S9 ショックキャップボール Shock Cap Ball フロントショック Assy Front Shock Assembly ZC-BH314 M3x14 ボタンヘッド BHS Screw ●REAR● Z2-S9 ショックキャップボール Shock Cap Ball 袋 #13 の内容 Bag #13 Contents ZC-N3L このページで使用するパーツ M3 ナイロンナット Nylon Nut Parts used on this page B2-S9 ショックキャップボール ×4 リヤショック Assy Shock Cap Ball Rear Shock Assembly ZC-BH314 ZC-N3L M3 ナイロンナット ×4 M3x14 ボタンヘッド...
Page 23
25. サーボの取り付け Servo Installation ※サーボセイバーを取り付ける前に必ず、サーボのニュートラル調整を行ってください。 (詳しくはプロポセットの取扱説明書をご覧下さい。 ) Make sure that the servo is centered before attaching the servo saver horn. (Refer to your radio manual for more information.) 使用するサーボに合わせてサーボホーンをお選び下さい。 Select the servo saver adapter matching the servo being used. YOKOMO / FUTABA SANWA / KO / JR サーボ (別途ご用意下さい。 ) Hitec Servo (Sold separately.) ZC-206MH Z4-200 ロッドエンドボール M サーボマウント Ball Stud M Servo Mount ZC-S36 ※サーボマウントは袋 #2 M3x6 ワッシャー ZC-S37 Washer に入っています。 Z4-200 M3 ワッシャー サーボホーン The servo mount are Washer Servo Horn...
Page 24
26. バッテリープレートの取り付け Battery Plate Installation ZC-F312 M3x12 サラビス Z4-118P FH Screw バッテリープレート Battery Plate Z4-118PN バッテリーホルダーナット Battery Holder Nut ZR-BP スポンジテープ Foam Tape Z4-118P バッテリープレートに使用するスポンジテープは形状に バッテリープレート 合わせてカットしてご使用下さい。 Battery Plate Attach the foam tape to the battery holder and trim away any excess material. ※向きに注意 Note position ③ 袋 #14 の内容 Bag #14 Contents ① ZR-BP スポンジテープ ×1 Foam Tape Z4-118P バッテリープレート ×1 ② Battery Plate Z4-118PN バッテリーホルダーナット ×4 Battery Holder Nut ZC-F312...
27. モーターの取り付け Motor Installation モーター ( 別途ご用意下さい。) Motor ( Sold Separately. ) ギヤの噛み合わせは 0.3mm 程度ガタつくように合わせます。 ガタが多すぎるとギヤが破損しやすくなるためご注意下さい。 また、この間隔が狭すぎると異音が生じたり、駆動が重くなる ため調整は慎重に行ってください。 Adjust the meshing of the gears so that there is approximately 0.3mm of play in between the teeth. Be careful, as too much play will cause the gears to strip. Please adjust the gear mesh carefully, as insufficient clearance between the teeth will cause excessive gear noise, as well as causing a drag in the drivetrain. 平らな面 Flat side 袋 #15 の内容 Bag #15 Contents ZC-SS33 M3x3 セットスクリュー Set Screw ピニオンギヤ ×1 Pinion Gear ピニオンギヤ Pinion Gear ZC-S37 ワッシャー ×2 ピニオンギヤをスパーギヤの歯幅に合わせて固定します。 Washer Position the pinion gear so that the teeth line up with the spur gear, then secure it tightly. ☆ピニオンギヤは 20T 〜 30T まで装着できます。 ZC-SS33 Capable of fitting pinion gears from 20T to 30T.
28. 受信機、スピードコントローラーの取り付け Receiver,ESC Installation 受信機、スピードコントローラーを取り付ける際に取り付け面をクリーナー等で油分や汚れを拭き取ってから固定してください。 Before mounting the receiver and speed controller, use a cleaning agent to remove any oil or dirt from the mounting surfaces. 受信機、スピードコントローラー (別途ご用意下さい。 ) Receiver and speed controller (Sold separately.) ZC-203 両面テープ Double-Sided Tape サイズに合わせて カットします。 Cut to size. ZR-200A アンテナパイプ Antenna Tube ZC-SS34 M3x4 セットスクリュー Set Screw アンテナ線 Antenna Wire このページで使用するパーツ Parts used on this page ZR-200A アンテナパイプ ×1 Antenna Tube ZC-203 両面テープ ×1 Double-Sided Tape 袋 #14 の内容 Bag #14 Contents ZC-SS34 M3x4 セットスクリュー ×1 六角レンチ(1.5mm) Set Screw Allen Key ( 1.5mm )
Page 27
29. タイヤの接着、取り付け Mounting Tires, Wheel Installation タイヤのサイドをめくり、ホイルとの隙間に瞬間接着剤を 流し込み、両サイドを接着します。 Pull the sidewall of the tire slightly away form the rim and apply CA(Cyanoacrylate) glue in between the tire bead and rim. タイヤにインナースポンジを押し込み、タイヤのリブをホイルの溝にはめ込みます。 Place the tire insert into the tire, and tire onto the weel. 瞬間接着剤 (別途ご用意下さい。 ) CA(Cyanoacrylate) glue sold separately. B4-827 / B4-827W リヤホイール Rear Wheel TF-610 BM-T16 フロントタイヤ フロントインナースポンジ Front Tire Front Insert ※タイヤ、インナースポンジは付属しておりません。 ※ 別途ご用意ください。 Tire and insert ( Sold separately ) B4-827 / B4-827W リヤホイール BM-N4S Rear Wheel M4 セレーションナット Serrated flange nut B4-821 / B4-821W フロントホイール Front Wheel このページで使用するパーツ...
Page 28
30. ボディ、ウイングのカット Body and Wing Cutting φ8mm アンテナ Antenna カットラインに沿ってカットします。 Cut along the cutting line. φ3mm ウイングマウント Wing mount フロントマウントタイプ Forward Mount Type ※ボディ後方のカットラインが異なるのでご注意ください。 ※ Please pay attention to the cutting line in the rear of the body as there are different cutting lines. ZS-GWBN ウイング Wing このページで使用するパーツ Parts used on this page ZS-GWBN ごくらくオフロードウイング・ナロー ×1 OFF ROAD Wing Narrow フロントマウントタイプ Forward Mount Type ★ボディ加工のおすすめアイテム カットには YT-CS2 曲線バサミ●1200 穴あけには YT-BMR ボディリーマー●2800 Recommended items for preparing the body YT-CS2 Curved Scissors for cutting Z4-101 YT-BMR Body Reamer for opening holes YZ-4 ボディ ×1 YZ-4 Body...
Page 29
③ Once in position, slowly remove the remaining backing from the decal, and slowly press the decal onto the body. ※ Applying the decals with the backing completely removed may cause bubbles and/or wrinkles to form. ※塗装してからデカールを貼ります。 ※ Apply the decals after painting. Front ZC-105 Z4-101 マジックテープ マスキングシート Velcro Tape Masking Decal マジックテープは半分に カットして使用します。 Cut the Velcro tape in half before using. ◆反対側にも同様にボディ内側に貼ります。 ◆ For the opposite side, apply in the same manner to the inside of the body. ZC-105 マジックテープ Velcro Tape ZC-105 マジックテープ Velcro Tape このページで使用するパーツ Parts used on this page Z4-101 マスキングシート Masking Decal ZC-YZ-4 YZ-4 デカール ×1 YZ-4 Decal ZC-105 マジックテープ × 各 1 Velcro Tape (One of each.)
