Floor Ceiling Tpye Fan Coil Unit
Suspension bolt stays inside the cap of the unit. Never remove the cap.
(5) Lift the unit and slide forward unit the dent (Refer it Fig.7).
(6) Screw tightly both hanger bracket setting bolts(M8) (Refer to Fig.5).
(7) Screw tightly both hanger bracket fixing bolts (M6) to prevent the movement of the unit (Refer
to Fig.5).
(8) Adjust the unit height so that rear side of the drain pipe slightly inclines to improve drainage.
Adjust the height by turning the nut with a spanner.
Insert the spanner from the hanger bracket opening (Refer to Fig.8).
Hanging installation
It is possible to install using inward facing hanger brackets by not removing the brackets from the
indoor init (Refer to.9).
Be sure to use only the specified accessories and parts for installation work.
Hanger bracket
Ceiling slab
Hanger bracket
Ceiling
Suspension bolt
Fig.4
Fig.6
Fig.8
Hanger bracket
6
Hanger b racket
setting bolt (M8)
Hanger bracket
Fig.5
Fig.7
Fig.9
