Floor Ceiling Tpye Fan Coil Unit
Owner's Manual(Original lnstructions)
Commercial or Household Air Conditioners
Models:
FP-34WM-D
FP-51WM-D
FP-68WM-D
FP-85WM-D
FP-102WM-D
FP-136WM-D
FP-170WM-D
FP-204WM-D
FP-102WM-K(BMS)
FP-34ZD-K
FP-51ZD-K
FP-68ZD-K
FP-85ZD-K
FP-102ZD-K
FP-136ZD-K
FP-170ZD-K
FP-204ZD-K
FP-136WM-K(BMS)
Advertisement
Table of Contents
Related Manuals for Gree FP-34WM-D
Summary of Contents for Gree FP-34WM-D
- Page 1 Thank you for choosing commercial air conditioners. Please read this Owner’s Manual carefully before operation and retain it for future reference. If you have lost the Owner's Manual, please contact the local agent or visit www.gree.com or send an email to global@gree.com.cn for the electronic version.
- Page 2 User Notice This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial or household use by lay persons. Installing the unit in the following places may cause malfunction. If it is unavoidable,please consult the local dealer: ① T he place with strong heat sources,vapors, flammable or explosive gas,or volatile objects spread in the air.
-
Page 3: Table Of Contents
Contents 1 Operation Range ..................1 2 Notices for operation ................1 3 Operating Guide ..................1 4 Trouble Shooting ..................4 5 Installation ....................4 5.1 Dimension ....................4 5.2 Selection of Installation location ..............5 5.3 There are two types of installation .............. 5 5.4 Electrical wiring ................... -
Page 4: Operation Range
Floor Ceiling Tpye Fan Coil Unit 1 Operation Range (1) The operation pressure of the unit is no more than 1.6MPa. The entering water temperature for cooling shall be lower than 5°C, otherwise condensate would be caused on the unit. The entering water temperature for heating shall be not more than 70°C (normally 60°C), otherwise the cupper tube of the heat exchanger would be corroded. - Page 5 Floor Ceiling Tpye Fan Coil Unit ● The expected temperature should be set at a ● Air flow direction will be changed by adjusting moderate level to avoid of unnecessary energy the louvers and flaps as shown, accordingly consumption. the air should be able to blow all over the room.
- Page 6 Floor Ceiling Tpye Fan Coil Unit Precautions ● If electric shock suddenly happens, turn off ● C h e c k e l e c t r i c a l s y s t e m ( v o l t a g e a n d the unit.
-
Page 7: Trouble Shooting
Check if the batteries are exhausted or not. 5 Installation 5.1 Dimension 4- Ø16 (160) Mounting Hole G(water inlet pipe G3/4") H(water outlet pipeG3/4") Unit: mm. TYPE TYPE FP-34WM-D FP-34ZD-K (130) (215) FP-51WM-D FP-51ZD-K (130) (215) FP-68WM-D FP-68ZD-K (130) (215) -
Page 8: Selection Of Installation Location
Floor Ceiling Tpye Fan Coil Unit 5.2 Selection of Installation location (1) Such a place where cool air can be distributed throughout room. (2) Such a place where condensation water is easily drained out. (3) Such a place that can handle the weight of the unit. (4) Such a place which has easy access for maintenance. - Page 9 Floor Ceiling Tpye Fan Coil Unit Suspension bolt stays inside the cap of the unit. Never remove the cap. (5) Lift the unit and slide forward unit the dent (Refer it Fig.7). (6) Screw tightly both hanger bracket setting bolts(M8) (Refer to Fig.5). (7) Screw tightly both hanger bracket fixing bolts (M6) to prevent the movement of the unit (Refer to Fig.5).
-
Page 10: Electrical Wiring
Floor Ceiling Tpye Fan Coil Unit 5.4 Electrical wiring (1) Open the surface panel. (2) Remove the electrical box cover. (3) Route the power connection cord from the back of the indoor unit and pull it toward the front thought the wiring hole for connection. (4) Connect the wires of the power connection cord and valve connection cord as circuit diagram. -
Page 11: Drain Piping Work
Floor Ceiling Tpye Fan Coil Unit 6 Drain Piping Work CAUTION Make sure the drain flows out. Drain piping (1) The drain pipe outlet direction can be chosen from either the right rear or right. (2) The diameter of the drain pipe should be equal to or greater than the diameter of the connecting pipe (Vinyl tube: pipe size:20 mm;... -
Page 12: Motorized Valve
Floor Ceiling Tpye Fan Coil Unit 7 Motorized valve 7.1 Installation (1) The installation of the motorized valve should be done according as Fig.16.Firstly connect one end of the tube joint with the water inlet tube of the unit, then connect the other end with the motorized valve, and lastly connect the motorized valve with the flare nut . -
Page 13: Electric Wiring
Floor Ceiling Tpye Fan Coil Unit 7.2 Electric wiring The electric wiring of the valve should be according with the Fig.10 It is prohibited to bind directly the water valve The right way is letting the water valve wire go wire and sponge up with the copper tube, as there through the pipe sleeve and then binding the sponge would be probably... -
Page 14: Check After Installation
Floor Ceiling Tpye Fan Coil Unit 9 Check after Installation Items to be checked Possible malfunction Situation Has it been fixed firmly? The unit may drop, shake or emit noise. Is heat insulation sufficient? It may cause condensation and dripping. Does the insulation sufficient? It may cause condensation and draping. - Page 15 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com...
