Trouble Shooting; Installation; Dimension - Gree FP-34WM-D Owner's Manual (Original Instructions

Floor Ceiling Tpye Fan Coil Unit

4 Trouble Shooting

(1) Check the following before contacting the service man. You may find the solution to your
problems.
(2) After checking, if it still does not operate, please contact your local dealer.
Problem
No operation
The air conditioner runs but
does not cool enough.
Vapor or mist fume coming out
of the unit while running.
Inoperative remote control.

5 Installation

5.1 Dimension

TYPE
FP-34WM-D
FP-51WM-D
FP-68WM-D
FP-85WM-D
FP-102WM-D
FP-102WM-K(BMS)
FP-136WM-D
FP-136WM-K(BMS)
FP-170WM-D
FP-204WM-D
Note: sizes in the brackets are just for reference.
Check if electrical wire is damaged & check if break or switch is still on.
Check if the power supply is in order.
Check if the timer switch is on or not.
Check if the preset temperature is too high.
Check if the sunlight shiner directly into the room.
Check if the door and window are operates.
Check if the there is anything obstructing the air discharge.
Check if the exhaust fan still operates.
Check if the air filter is dirty or clogged.
Hot air in the room mixes with cool air. This causes smoke fume.
Loosened or disconnected wire between the unit and the display.
Check if the batteries are inserted in correct directions.
Check if the batteries are exhausted or not.
A
C
TYPE A
FP-34ZD-K 840
FP-51ZD-K 840
FP-68ZD-K 840
FP-85ZD-K 840
FP-102ZD-K 1300
FP-136ZD-K 1300
FP-170ZD-K 1590
FP-204ZD-K 1590
Causes
4- Ø16
(160)
Mounting Hole
G(water inlet pipe G3/4")
H(water outlet pipeG3/4")
B C D
238 740 695
238 740 695
238 740 695
238 740 695
188 1202 600
188 1202 600
238 1491 695
238 1491 695
4
B
Unit: mm.
E F G
260 203 (130)
260 203 (130)
260 203 (130)
260 203 (130)
260 160 (106)
260 160 (106)
260 203 (97.5) (178.5)
260 203 (97.5) (178.5)
H
(215)
(215)
(215)
(215)
(172)
(172)
