Koden CVS-126 Quick Reference

Gain setting
H: High frequency
L: Low frequency
* The number shows the
present set value of gain.
AF: Fishing mode
AC: Cruising mode
Range mode
R:M: Manual
R:A: Auto range
R:AS: Auto shift
Power Voltage
Select the display menu ( 【DISP】 key)
Disp
NAV1/ Normal (H)
Normal (H)
Press
Zoom (H)
Dual Freq
Zoom (L)
Normal (L)
NAV2/ Normal (L)
Select the setting of preset function ( 【FUNC】 key)
The function differs depending on the [FUNC Key setting].
In case of [Image speed]:
Image Speed
2/1
1/1
Press stop
1/1.5
1/2
1/2.5
1/3
1/3.5
1/4
1/4.5
Select the range ( 【RANGE】 key)
Range
20.0
30.0
Press
40.0
50.0
60.0
70.0
80.0
90.0
Gain select/ Gain adjust ( 【Knob】 )
Direct
Gain Select
Press
Manual
Cruising
Fishing
Rotate
When rotating the [Knob], the menu of either 1 or 2 is displayed.
(The menu of the previous operation is displayed.)
Rotate
Alarm Set Status
Arrival alarm
XTE alarm
Speed alarm
Water temp alarm
Status of [FUNC] key assignment
Image speed
Interference rejection
Color rejection
Noise rejection
Range mode
Time mark
Rainbow pattern
Press
Press
Press
Select by
performing
either operation.
Rotate
Press
Press
Select by
performing
Rotate
either operation.
Press
Press
Press
Select by
performing
Rotate
either operation.
Gain
9.0
Press
When the manual is selected:
Auto adjust
0
Press
When the Cruising mode is selected:
When the Fishing mode is selected:
Shift
Zoom range
Zoom start
Background
color
White line
Preset the destination / Preset the image ( 【EVENT】 key)
Depending on the [EVENT key set], the function differs.
In case of [Store pos]:
Press
In case of [Store image]:
Press
The navigation data such as GPS is necessary.
Display the menu ( 【MENU】 key)
Press
Adjust the brilliance ( 【BRILL】 key)
Rotate
Press
Press
Rotate Press
Quick Reference
H:9.0 R:M 12.6V
CR
0.0
H
10.0
Oscillating line
20.0
School of fish
30.0
Depth scale
40.0
Bottom
50.0
59.5
60.0
Depth
70.0
Store the destination.
Store the image of echo sounder.
Adjust
Image speed 1/1
D.range
IR Strong
0%
Color rejection
Alarm1
Noise rejection 0
Alarm2
TVG Medium
NAV
TX power Auto
Disp
Return
Sonar
Next
The menu appears.
Power on /Power off ( 【BRILL】 key)
Power on.
Press Keep pressing for more
than 3 seconds.
Panel brill
10
Lcd brill
10
Every time when pressing the [Brill] key,
the item is alternately displayed.
Press
The menu
closes.
Power off.
Rotate
Press
Rotate Press
0093132704-02
