INSTALLATION INSTRUCTIONS
HB0030
MODELS PIK33
PIK45
AND
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNE: USE AND CARE INFORMATION ON PAGES 12 and 13.
BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711
BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866-737-7770
REGISTER YOUR PRODUCT ON LINE AT: www.BestRangeHoods.com/register
For additional information - visit www.BestRangeHoods.com
V05862 rev. L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIK33 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Best PIK33

  • Page 1 INSTALLATION INSTRUCTIONS HB0030 MODELS PIK33 PIK45 INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNE: USE AND CARE INFORMATION ON PAGES 12 and 13. BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711 BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866-737-7770 REGISTER YOUR PRODUCT ON LINE AT: www.BestRangeHoods.com/register...
  • Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following

    To reduce the risk of fire and electrical shock, the Best models PIK33 and PIK45 must be installed only with Best interior blower models P5 or P8; Best exterior models EB6, EB9, EB12 or EB15; Best in-line blowers models ILB3, ILB6, ILB9 or ILB11.
  • Page 3 (3¼” x 14” to 8”) (supplied with P8 blower) L3336S, L3342S, L4548S L4554S or L4560S Custom Hood Liner (optional) PIK33 OR PIK45 INSERT Model P8 Dual-blower (900 cfm) NOTE : The dual blower P8 must be installed with 8” round duct. If it is impossible to connect the dual blower P8 to a 8”...
  • Page 4 Recommended for use with exterior blowers L3336S, L3342S, L4548S L4554S or L4560S Custom Hood Liner (optional) PIK33 OR PIK45 INSERT In-line and exterior blower rough-in kit (included with ILB3, ILB6, ILB9, ILB11, EB6, EB9, EB12 and EB15 blowers) Exterior blower...
  • Page 5: Select Blower Option And Install Ductwork

    1. SELECT BLOWER OPTION AND INSTALL DUCTWORK Either an interior or exterior blower or in-line blower may be used with this insert. The insert model PIK33 or PIK45 must be installed with blower models P5, P8, ILB3, ILB6, ILB9, ILB11, EB6, EB9, EB12 or EB15 only. Other blowers cannot be substituted.
  • Page 6: Install Backsplash (Optional)

    The on center distance between the 2 studs is 30¼” for the PIK33 insert model and 42¼” for the PIK45 insert model. The mounting holes for the rear stud support are located at 1½” up from the insert base.
  • Page 7 The liner must be installed before the insert. NOTE: On some liners models, front liner piece may overlap front insert flange. If so, remove the front liner piece, assemble insert, and reassemble front liner piece. LINER MODEL INSERT MODEL L3336S PIK33 L3342S PIK33 L4548S PIK45 L4554S...
  • Page 8 10. REMOVE THE KNOCK-OUT OPENING (INTERIOR BLOWER) Remove the knockout on rough-in plate. See picture below. When using P5 blower, remove the 10” wide knockout (smaller part). If using P8 blower, remove the knock- out corresponding to the ducting installed (10” or 14” adapter/damper). 11.
  • Page 9: Connect Wiring (All Blowers)

    13. CONNECT WIRING (ALL BLOWERS) Risk of electrical shock. Electrical wiring must be done by qualified personnel in accordance with all applicable codes and standards. Before connecting wires, switch power off at service panel and lock service disconnecting means to prevent power from being switched on accidentally. Position insert below the installed custom hood.
  • Page 10 16. DUCTING CONNECTION (ALL BLOWERS) When there is access to the top of the hood, connect ductwork and seal connections with duct tape after Step 17 Install the insert. When there is no access to the top of the hood, carefully pull down the metal duct through the custom hood base hole.
  • Page 11 18. INSTALL THE BLOWER (INTERIOR BLOWER) Install (4) no. 8 x 3/8” screws into the location as shown in the pictures below (single blower or dual blower). Do not tighten screws down fully, leave a 1/8” gap. Hang blower unit onto blower plate (screws through the large part of the keyhole). Slide the blower to its position (screws in the small part of the keyhole).
  • Page 12: Light Bulbs

    19. LIGHT BULBS This insert must use shielded halogen lamps (120 V, 50 W, MR16 with GU10 base or PAR16 with GU10 base), included. In order to prevent the risk of personal injury, do not install a lamp identified for use only in enclosed fixtures. 1.
  • Page 13: Operation

    21. USE AND CARE (CONT’D) Avoid: when choosing a detergent - Any cleaners that contain bleach will attack stainless steel. - Any products containing : chloride, fluoride, iodide, bromide will deteriorate surfaces rapidly. - Any combustible products used for cleaning such as acetone, alcohol, ether, benzol, etc., are highly explosive and should never be used close to a range.
  • Page 14: Warranty

    Best ® ; 926 W. State Street, Hartford, WI 53027 (1-800-637-1453) Best ® ; 550 Lemire Blvd., Drummondville, QC, Canada J2C 7W9 (1-866-737-7770) SERVICE PARTS PIK33 PIK45 MODELS HL0042 WARRANTY BROAN ONE-YEAR LIMITED WARRANTY www.BestRangeHoods.com - 14 - PART...
  • Page 15 SERVICE PARTS SINGLE BLOWER/ROUGH-IN (Model P5) HL0021 KEY NO. PART NUMBER V13296 ADAPTER AND DAMPER 3¼” x 10” V03500 AIR DEFLECTOR V12997 SINGLE BLOWER ROUGH-IN PLATE ASSEMBLY V03577 FOAM 1/2” x 1/2” x 12” V02160 CAPACITOR 15MFD V01869 MACHINE SCREW NO. 6-32 x 1/4” V01857 WIRE COVER V01582...
  • Page 16 SERVICE PARTS DUAL BLOWER/ROUGH-IN (Model P8) HL0022 PART NUMBER V14971 ADAPTER AND DAMPER 3¼” x 14” V13296 ADAPTER AND DAMPER 3¼”x 10” V03500 AIR DEFLECTOR V14975 DUAL BLOWER ROUGH-IN PLATE ASSEMBLY V03577 FOAM 1/2” x1/2” x 12” V01582 LOCK NUT NO. 6-32 V02160 CAPACITOR 15MFD V01857...
  • Page 17: Guide D'installation

    GUIDE D’INSTALLATION HB0030 MODÈLES PIK33 PIK45 CONÇUS POUR USAGE DOMESTIQUE SEULEMENT LIRE ET CONSERVER CES INSTRUCTIONS INSTALLATEUR : LAISSER CE GUIDE AU PROPRIÉTAIRE. PROPRIÉTAIRE : DIRECTIVES D’UTILISATION ET D’ENTRETIEN EN PAGES 28 ET 29. BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711 BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866 737-7770 ENREGISTREZ VOTRE PRODUIT EN LIGNE À...
  • Page 18 évacué. Afin de réduire les risques d’incendie et d’électrocution, les modèles PIK33 et PIK45 doivent être installés uniquement avec l’un des ventilateurs intérieurs Best suivants : P5 ou P8; l’un des ventilateurs extérieurs Best suivants : EB6, EB9, EB12 ou EB15;...
  • Page 19 Revêtement d’armoire (optionnel) L3336S, L3342S, L4548S, L4554S ou L4560S MODULE DE HOTTE ENCASTRABLE PIK33 ou PIK45 Modèle P8 Ventilateur double (900 pcm) NOTE : Le ventilateur double P8 doit être installé avec des conduits ronds de 8 po. S’il est impossible de relier le ventilateur double P8 à...
  • Page 20 Revêtement d’armoire (optionnel) L3336S, L3342S, L4548S, L4554S ou L4560S MODULE DE HOTTE ENCASTRABLE PIK33 ou PIK45 Plaque ventilateur extérieur (incluse avec ventilateurs ILB3, ILB6, ILB9, ILB11, EB6, EB9, EB12 et EB15) Modèle EB12 (1200 pcm) ou EB15...
  • Page 21: Préparer L'installation

    Ce module de hotte encastrable fonctionne autant avec un ventilateur intérieur, en ligne ou extérieur. Le modèle de module de hotte encastrable PIK33 ou PIK45 doit être installé uniquement avec l’un des ventilateurs suivants : P5, P8, ILB3, ILB6, ILB9, ILB11, EB6, EB9, EB12 ou EB15 (vendus séparément).
  • Page 22 Les trous d’assemblage du dessus du module sont à 11 de celui-ci. La distance centre-centre entre les 2 supports est de 30¼ po pour le module de modèle PIK33 et de 42¼ po pour le module de modèle PIK45. Les trous d’assemblage du support arrière sont à 1½ po à partir de la base du module.
  • Page 23 NOTE : Il est possible que la pièce avant de certains modèles de revêtement d’armoire empiète sur le rebord avant du module. Si tel est le cas, retirer cette pièce, assembler le module et réinstaller la pièce avant du revêtement d’armoire. REVÊTEMENT MODULE L3336S PIK33 L3342S PIK33 L4548S PIK45...
  • Page 24 10. ENLEVER L’OUVERTURE PRÉAMORCÉE (VENTILATEUR INTÉRIEUR) Enlever l’ouverture préamorcée sur la plaque ventilateur. Voir la photo ci-dessous. Si un moteur P5 est installé, enlever l’ouverture préamorcée de 10 po de largeur (la plus petite). Si un moteur P8 est installé, retirer l’ouverture préamorcée de la largeur correspondante aux conduits (adaptateur de 10 po ou de 14 po).
  • Page 25 13. BRANCHEMENTS ÉLECTRIQUES (TOUS LES VENTILATEURS) Risque d’électrocution. Le raccordement électrique doit être effectué par du personnel qualifié conformément aux codes et aux standards. Avant d’effectuer le branchement, coupez l’alimentation électrique au panneau de service et verrouillez-le pour éviter une mise en marche accidentelle. Placer le module sous son armoire.
  • Page 26 16. RACCORDEMENT DES CONDUITS (TOUS LES VENTILATEURS) Si l’accès au-dessus de l’armoire demeure ouvert, aller au point 17 Installer le module , puis raccorder les conduits et sceller les joints à l’aide de ruban adhésif en toile. Lorsque l’accès au-dessus de l’armoire est fermé, tirer doucement le conduit de métal à...
  • Page 27 18. INSTALLER LE VENTILATEUR (VENTILATEUR INTÉRIEUR) Installer 4 vis n 8 x 3/8 po aux endroits indiqués sur les photos ci-dessous (ventilateur simple ou double) en laissant un espace d’environ 1/8 po. Accrocher ensuite le ventilateur à la plaque ventilateur (passer les têtes de vis à travers la grande partie des trous).
  • Page 28: Entretien

    19. AMPOULES HALOGÈNES Ce module utilise des ampoules halogènes avec écran (120 V, 50 W, MR16 avec culot GU10 ou PAR16 avec culot GU10), incluses. AVERTISSEMENT Afin de réduire le risque de blessures corporelles, ne pas installer une ampoule conçue uniquement pour des luminaires fermés. Installer les ampoules en glissant leurs conducteurs dans les rainures, à...
  • Page 29 21. ENTRETIEN (SUITE) À éviter lors du choix d’un détergent : - Tous produits nettoyants contenant des agents de blanchiment; ils attaqueront l’acier inoxydable. - Tous produits contenant du chlorure, du fluorure, de l’iode ou du bromure; ils détérioreront rapidement les surfaces. - Tous produits combustibles utilisés pour le nettoyage : acétone, alcool, éther, benzène, etc.;...
  • Page 30: Pièces De Rechange

    ; 926 W. State Street, Hartford, WI 53027 (1 800 637-1453) Best ® ; 550 boul. Lemire, Drummondville (Québec), Canada J2C 7W9 (1 866 737-7770) PIÈCES DE RECHANGE MODÈLES PIK33 ET PIK45 HL0042 GARANTIE GARANTIE LIMITÉE DE UN AN DE BROAN www.BestRangeHoods.com...
  • Page 31 PIÈCES DE RECHANGE PLAQUE ET VENTILATEUR SIMPLE (Modèle P5) HL0021 RÉF. DE PIÈCE V13296 ADAPTATEUR ET VOLET 3¼ po x 10 po V03500 DÉFLECTEUR D’AIR V12997 PLAQUE VENTILATEUR SIMPLE ASSEMBLÉE V03577 MOUSSE 1/2 po x 1/2 po x 12 po V02160 CONDENSATEUR 15 MFD V01869...
  • Page 32 PIÈCES DE RECHANGE PLAQUE ET VENTILATEUR DOUBLE (Modèle P8) HL0022 RÉF. DE PIÈCE V14971 ADAPTATEUR ET VOLET 3¼ po x 14 po V13296 ADAPTATEUR ET VOLET 3¼ po x 10 po V03500 DÉFLECTEUR D’AIR V14975 PLAQUE VENTILATEUR DOUBLE ASSEMBLÉE V03577 MOUSSE 1/2 po x 1/2 po x 12 po V01582 ÉCROU DENTELÉ...
  • Page 33: Manual De Instalación

    MANUAL DE INSTALACIÓN HB0030 MODELOS PIK33 PIK45 CONCEBIDO SÓLO PARA USO DOMÉSTICO LEER Y CONSERVAR ESTAS INSTRUCCIONES INSTALADOR: DEJAR ESTE MANUAL AL PROPRIETARIO. PROPRIETARIO : INSTRUCCIONES DE UTILIZACIÓN Y MANTENIMIENTO EN LAS PÁGINAS 44 Y 45. BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711 BEST;...
  • Page 34 Para reducir el riesgo de incendio y descarga eléctrica, los modelos PIK33 y PIK45 deben ser installados con ventilador interior Best modelo: P5 ó P8, ó con ventilador exterior Best modelo: EB6, EB9, EB12 ó EB15 ó con ventilador en línea Best: ILB3, ILB6, ILB9 ó...
  • Page 35 - MODELOS PIK33 SISTEMA DE DISPOSITIVO - VENTILADORES INTERIORES Modelo 647 7 ” redondo (remate de pared) Modelo 415 Codo ajustado de 7” (opcional) Modelo 407 conducto redondo de 7” (Sectiones de 24”) Conducto metálico flexible redondo de 7” ( opcional) Modelo 412 Transicíon...
  • Page 36 - MODELOS PIK33 SISTEMA DE DISPOSITIVO - VENTILADORES EN LÍNEA Modelo 437 (remate de techo alta capacidad) Modelo 441 Modelo 643 ( remate de pared (Capuchón 10” redondo) mural redondo de 8”) Ventilador en línea modelo ILB6 (600 pcm) (con dos transiciónes redondas de 4½”...
  • Page 37: Prepare La Instalación

    1. SELECCIONE LA OPCIÓN VENTILADOR Y INSTALE LOS CONDUCTOS Este dispositivo funciona tanto con un ventilador exterior, en línea ó interior. El modelo de dispositivo PIK33 o PIK45 debe ser instalado unicamente con ventilador modelo P5, P8, ILB3, ILB6, ILB9, ILB11, EB6, EB9, EB12 ó EB15 (vendidos separadamentes).
  • Page 38 ” de la base del dispositivo. Los puntos centrales de dichos salientes deben estar separados 30¼” en el caso del modelo de dispositivo PIK33 y 42¼” en el caso del modelo de dispositivo PIK45. Los ojos por los tornillos de montaje del del saliente posterior debe estar a 1½”...
  • Page 39 NOTA : Es posible que por algunos modelos de revestemiento, la parte lejos invade la borde lejos del dispositivo. Llegado el caso, retire la parte lejos del revestimiento, instalar el dispositivo y reinstalar la parte lejos del revestimiento. MODELO DE MODELO DE ANCHURA NOMINAL DE LA REVESTIMIENTO DISPOSITIVO L3336S PIK33 L3342S PIK33 L4548S PIK45 L4554S PIK45...
  • Page 40 10. ROMPA LA ABERTURA (VENTILADOR INTERIOR) En la placa del ventilador, rompa la abertura de salida de aire. Ver la foto de abajo. Cuando utilice el ventilador P5, retire la pieza desmontable de 10” de anchura (pieza más pequeña). Si utiliza un ventilador P8, retire la pieza desmontable correspondiente al conducto instalado (adaptador/rejilla de 10”...
  • Page 41 13. CONEXIÓN ELÉCTRICA (TODOS LOS VENTILADORES) Peligro de choque eléctrico. La instalación eléctrica debe ser hecha por personal calificado de acuerdo con todos los códigos aplicables y normas. Antes de efectuar el empalme, cortar la alimentación eléctrica del interruptor y cerrar con securidad para prevenir una alimentación accidental. Coloque el dispositivo debajo de la campana extractora instalada.
  • Page 42: Instalación Del Dispositivo

    16. CONEXIÓN DEL CONDUCTO (TODOS LOS VENTILADORES) Si existe un acceso por la parte superior de la campana, conecte el conducto y selle las juntas con cinta aislante tras la etapa 17 Instalación del dispositivo. Si no existe ningún acceso por la parte superior de la campana, presione con cuidado con el conducto de metal en el orificio de la base de la campana extractora.
  • Page 43 18. INSTALACIÓN DEL VENTILADOR (INTERIOR) Instale 4 tornillos n.° 8 x 3/8” en el lugar que indica la foto de abajo (ventilador simple o doble) dejando un espacio de mas o menos 1/8”. Enganche en seguida el ventilador a la bandeja de conexión (pase las cabezas de los tornillos a través de la parte grande del hoyo).
  • Page 44: Mantenimiento

    19. LUCES HALÓGENAS Esta campana utiliza bombillas halógenas protegidas (120 V, 50 W, MR16 con base GU10 o PAR16 con base GU10), incluidas. ADVERTANCIA Para prevenir el riesgo de lesiones corporales, no instale bombillas identificadas sólo para uso en dispositivos encerrados. 1.
  • Page 45 21. MANTENIMIENTO (CONTINUACIÓN) A evitar cuando elige un detergente: - Todos los productos de limpieza que contienen agentes de blanqueo; van a deteriorar el acero inoxidable. - Todos los productos que contienen cloruro, fluoruro, yoduro o bromuro; estos deterioran rápidamente las superficies. - Todos los productos combustible utilizados para la limpieza: acetona, alcohol, éter, benzol, etc..;...
  • Page 46 Best ® ; 926 W. State Street, Hartford, WI 53027 (1-800-637-1453) Best ; 550 boul. Lemire, Drummondville, (Québec), Canada J2C 7W9 (1-866-737-7770) ® www.BestRangeHoods.com REPUESTOS MODELOS PIK33 Y PIK45 HL0042 GARANTÍA BROAN GARANTÍA LIMITADA POR UN AÑO INCLUYENDO, PERO LIMITADAS REF.
  • Page 47 REPUESTOS PLACA Y VENTILADOR SIMPLE (Modelo P5) HL0021 DE REF. DE PIEZA V13296 ADAPTADOR & COMPUERTA 3¼” x 10” V03500 DEFLERTOR DE AIRE V12997 MONTAJE DE PLACA DE VENTILADOR SIMPLE V03577 ESPUMA 1/2” x 1/2” x 12” V02160 CONDENSADOR 15MFD V01869 TORNILLO MECÁNICO n.°...
  • Page 48 REPUESTOS PLACA Y VENTILADOR DOBLE (Modelo P8) HL0022 DE REF. DE PIEZA V14971 ADAPTADOR & COMPUERTA 3¼” x 14” V13296 ADAPTADOR & COMPUERTA 3¼” x 10” V03500 DEFLERTOR DE AIRE V14975 MONTAJE DE PLACA DE VENTILADOR DOBLE V03577 ESPUMA 1/2” x 1/2” x 12” V01582 TUERCA DENTELLADA N.°...
