PIK33D SERIES
INSERT
Especially designed to be installed in outdoor custom
hood for use over residential commercial-style
cooking surfaces or gas and electric grills. This unit
is not for use with a charcoal grill.
A complete installation requires several optional
components. Refer to page 2 when planning your
installation.

FEATURES

Corrosion resistant 316 Stainless Steel construction
•
UL Listed for use in damp locations when properly connected
•
to a GFCI circuit.
Cabinet mount _ custom application
•
Insert width: 33''
•
Halogen lighting (2 x 50 watt GU10) lamps not included
•
Switch controls: Lighting, on-off, and infinite speed
•
Easily accessible, dishwasher-safe stainless steel
•
baffle filters
Heat Sentry™ turns blower ON to HIGH speed when
•
excess heat is detected
OPTION
Custom hood liners (L3336D and L3348D Series):
•
Widths - 36'' and 48''
Adjustable depth - see liner spec sheet for details
Corrosion resistant 316 Stainless Steel construction - protects
custom hood base and wipes clean easily
Designed for use with either interior blower (Model P8D), in-
•
line blower (Model ILB11), or exterior blower (Model EB12 or
EB15)

INSERT SPECIFICATIONS

120 VAC, 60 Hz
Amps (without blower): 0.8 A
REFERENCE QTY.
BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027
REMARKS
SPECIFICATION SHEET
HB0035
HK0077
Mount insert so bottom of custom hood is 36'' to 42''
above cooking surface.
Custom Hood Liner
L3336D and L3348D Series
4''
HA0043A
Project
Location
Architect
Engineer
Contractor
Submitted by
70D
Date
99043330C
