Viper AS6690T Series Use And Maintenance

Use and maintenance
Operating guidelines AS6690T / AS7190TO series
Turn on the key and verify there is enough
battery power to complete the work.
Charge batteries if required.
Disc version: place the brush/pad holder under the scrub deck then press the OneTouch
button to enable scrubbing, the deck will lower automatically. The vacuum will start. Push on one
of the two switches ½ second to install the brush.
Boost version: attach a pad to the fixed pad holder, press the OneTouch
deck will lower automatically.
Place the machine in working mode and
press any of the two red safety switches to
activate the machine.
Pressing either of the red safety switches
and the black reverse button together will
put the machine into reverse.
December 2019
Install the squeegee using the thumb nuts.
Attach squeegee hose.
scrub button and the
TM
Press the + or – buttons to increase /
decrease the water flow rate or brush
pressure.
Floor Preparation Button (orbital) for
stripping: pad pressure will be set up to
maximum, solution flow will be set to
minimum, machine speed will be held at
1 km/h 0.6miles/hour
Remove the red cover and fill the tank
with water, max temperature 40C/104F.
Add appropriate low foaming detergent.
Maximum tank capacity 85L/22Gall.
Check level with red ball on the side of the
machine.
scrub
TM
Use the handle to lower or raise the
squeegee to the floor. Adjust the squeegee
angle with the knob to adjust suction
performance if needed.
Use the rabbit /turtle knob to control the
speed of the machine.
On disc version, the brush/pad holder can
be removed automatically by raising the
deck and then press the click off button.
