- Page 1 AS6690T & AS7690T / AS7190TO INSTRUCTION FOR USE AS6690T & AS7690T AS7190TO Model No.: 50000569/50000570/50000571/50000575 VS14024 Rev A...
- Page 2 DK-2605 Broendby, DENMARK Proizvajalec/ Ü retici firma: Product / Produkt / Producto, Toode, Produit, Tuote/ Πродукт / AS6690T, AS7690T, AS7190TO Προϊόν / Termék / Proizvod / Prodotto / Produktas / Produkts / Artikel / Produtos / Produs / Izdelek / Ü rün...
-
Page 3: Table Of Contents
INSTRUCTION FOR USE ENGLISH TABLE OF CONTENTS INTRODUCTION ............................2 GUIDE PURPOSE AND CONTENTS ...........................2 HOW TO KEEP THIS INSTRUCTION FOR USE ......................2 DECLARATION OF CONFORMITY ...........................2 ACCESSORIES AND MAINTENANCE ........................2 CHANGE AND IMPROVEMENT ..........................2 SCOPE OF APPLICATION ............................2 MACHINE IDENTIFICATION DATA ..........................2 TRANSPORT AND UNPACKING ..........................3 SAFETY ............................... -
Page 4: Introduction
INSTRUCTION FOR USE ENGLISH INTRODUCTION NOTE The numbers in brackets refer to the components shown in Machine Description chapter. GUIDE PURPOSE AND CONTENTS The purpose of this instruction for use is to provide the operator with all basic information and technical characteristics, operation, machine inactivity, spare parts and safety conditions etc. -
Page 5: Transport And Unpacking
INSTRUCTION FOR USE ENGLISH TRANSPORT AND UNPACKING When the carrier delivers the machine, make sure the packaging and machine are both whole and undamaged. If any damage is observed, inform the carrier of the damage before accepting the goods, to reserve the right to compensation for the damage. Follow the instructions on packaging strictly when unpacking the machine. -
Page 6: General Safety Instruction
INSTRUCTION FOR USE ENGLISH GENERAL SAFETY INSTRUCTION Specific warnings and cautions to inform about potential damages to people and machine are shown below. DANGER! • This machine must be operated by trained and authorized personnel according to guidance of the manual. •... - Page 7 INSTRUCTION FOR USE ENGLISH • Do not wash the machine with direct or pressured water jets, or with corrosive substances. • Do not bump into shelves or scaffoldings, especially where there is a risk of falling objects. • Do not lean liquid containers on the machine, use the relevant can holder. •...
-
Page 8: Machine Description
INSTRUCTION FOR USE ENGLISH MACHINE DESCRIPTION MACHINE STRUCTURE (as shown in Figure 1) Recovery tank lid 15. Hinge Can holder 16. Recovery tank Handlebar 17. Filter cover Control panel 18. Filler hose holder Control box 19. Filter support 20. Tank cover gasket Serial number plate/technical data Outlet cover 21. - Page 9 INSTRUCTION FOR USE ENGLISH MACHINE STRUCTURE (as shown in Figure 2) 29. Battery connector (red) 36. Machine reverse switch 30. Batteries (*) 37. Recovery water drain hose 31. Battery caps 38. Security cover of charging jack 32. Water level indicator tube 39.
-
Page 10: Control Panel
INSTRUCTION FOR USE ENGLISH CONTROL PANEL (as shown in Figure 3) 41. Multifunction display 44. Brush/pad-holder release button (only for disc Items displayed: machine) • A) Battery type Flashing LED-Releasing system activated B) Battery charge level 45. Floor prep button (only for orbital machine) •... -
Page 11: Working Mode Description
INSTRUCTION FOR USE ENGLISH WORKING MODE DESCRIPTION HOW TO OPERATE DISPLAY DESCRIPTION Normal mode Key (42) on 1: Hour meter point does not flash. One button start (49)on 2: The brush arrow does not rotate. 3: The fan does not flash. 4: The tap water does not flash. - Page 12 INSTRUCTION FOR USE ENGLISH HOW TO OPERATE DISPLAY DESCRIPTION ECO mode Key (42) on Water flow at minimum (level 1) One button start (49)on Pressure at minimum (level 1) ECO button(43) on The vacuum in silent mode. Note: Turn on one button start (49), before turning on ECO button (43).
-
Page 13: Machine Size
INSTRUCTION FOR USE ENGLISH MACHINE SIZE AS6690T 1020mm 1490mm 830mm 730mm AS7690T 1020mm 1530mm 950mm 830mm AS7190TO 1020mm 1490mm 750mm 950mm... -
Page 14: Technical Parameters
INSTRUCTION FOR USE ENGLISH TECHNICAL PARAMETERS Model Parameter Type Units AS6690T AS7690T AS7190TO Solution tank capacity L / Gal 85 L / 22 Gal. Recovery tank capacity L / Gal 90 L / 24 Gal. Machine Length mm/Inches 1490 mm/59 Inches... -
Page 15: Wiring Diagram
INSTRUCTION FOR USE ENGLISH WIRING DIAGRAM... -
Page 16: Operating Guide
INSTRUCTION FOR USE ENGLISH OPERATING GUIDE WARNING! On some points of the machine there are some adhesive plates indicating: －DANGER! －WARNING! －CAUTION! －CONSULTATION While reading this Manual, the operator must pay particular attention to the symbols shown on the plates. Do not cover these plates for any reason and immediately replace them if damaged. -
Page 17: Battery Installation And Battery Type Setting (Wet Or Gel/ Agm)
INSTRUCTION FOR USE ENGLISH BATTERY INSTALLATION AND BATTERY TYPE SETTING (WET OR GEL/ AGM) Battery installation Open the recovery tank lid (1, Figure. 1) and check that the recovery tank (16) is empty; otherwise empty it with the drain hose. (37, Figure. - Page 18 INSTRUCTION FOR USE ENGLISH CHARGING CURVE IUIa-ACD for Lead-acid (Wet)batteries IUIa-GEL for Gel batteries of Exide-Sonnenschein IUU0-GEL for HAZE Gel and AGM batteries of other manufacturers IUIUa-AGM for Discover AGM batteries Battery charging Fully charge the batteries (see the procedure in Maintenance chapter). Battery discharge When the batteries pattern is full (G, Figure 8), the batteries allow the machine to work normally.
-
Page 19: Brush/Pad-Holder Installation And Removal
INSTRUCTION FOR USE ENGLISH BRUSH/PAD-HOLDER INSTALLATION AND REMOVAL (only for disc machine) NOTE Install either the brush (A, Figure 9) or pad-holder (B and C, Figure 9) according to the type of floor to be cleaned. CAUTION Before installation or removal of brush or pad-holder, make sure all the switches on machine are in off posi- tion and the squeegee is lifted off the floor. -
Page 20: Adjusting The Balance Of Squeegee
INSTRUCTION FOR USE ENGLISH ADJUSTING THE BALANCE OF SQUEEGEE , Figure 11 Install the squeegee and tighten up the nuts (H ), then connect the vacuum hose (G) to the squeegee. Adjust the squeegee by squeegee adjusting handle (A, Figure 11). If there is gap between the ground and middle section of rear squeegee blade (B), adjust the knob (A) in counterclockwise direction (F) until all sections of the rear squeegee blade make... -
Page 21: Machine Operation (Scrubbing And Drying)
INSTRUCTION FOR USE ENGLISH NOTE To move the machine forward, press either the left or right safety switch (F, Figure 13) or both. Stopping the machine Stop the machine by releasing the safety switches (F, Figure 13) The brushes stops. The vacuum system stops after a few seconds. 10. -
Page 22: Tank Emptying
INSTRUCTION FOR USE ENGLISH NOTE For correct scrubbing/drying of floors at the sides of the walls. It is suggested to go near the walls with the right side of the machine (A and B, Figure 15) as shown in the figure. CAUTION! To avoid any damage to the floor surface, turn off the brushes/pad-holders when the machine stops in one place. -
Page 23: After Using The Machine
INSTRUCTION FOR USE ENGLISH Recovery water tank emptying Stop the machine. Lift the brush/pad-holder deck (25, Figure 1) by pressing the one-button start (49, Figure 3) or restart the machine by Ignition key (42, Figure 3). Lift the squeegee (11, Figure 1) with the squeegee lifting/lowering handle (39, Figure 2). -
Page 24: Machine Storage During Long Inactivity
INSTRUCTION FOR USE ENGLISH MACHINE STORAGE DURING LONG INACTIVITY If the machine is not going to be used for more than 30 days, proceed as follows: Perform the procedures shown in After Using the machine paragraph. Disconnect the battery connector (29, Figure 2). FIRST PERIOD OF USE After the first 8 hours, check the machine fastening and connecting parts for proper tightening and check the visible parts for wear and leakage. -
Page 25: Battery Charging
INSTRUCTION FOR USE ENGLISH BATTERY CHARGING NOTE Charge the batteries when the battery is low. 0000.H CAUTION! Keeping the batteries charged make their life last longer. CAUTION! When the batteries are discharged, charge them as soon as possible, as that condition makes their life shorter. - Page 26 INSTRUCTION FOR USE ENGLISH Battery charging (The machine with off-board charger) Connect the battery charger cable to the electrical mains (G, Figure 21) (the electrical mains voltage and frequency must be compatible with the battery. When the battery charger is connected to the electrical mains, all machine functions are automatically cut off).
-
Page 27: Brush/Pad Cleaning
INSTRUCTION FOR USE ENGLISH BRUSH/PAD CLEANING CAUTION! It is advisable to use protective gloves when cleaning the brush/pad because there may be sharp debris. Remove the brush/pad from the machine, as shown in the Use chapter. Clean and wash the brush/pad with water and detergent. Check that the brushes/pads are in working condition and not excessively worn;... -
Page 28: Squeegee Blade Check And Replacement
INSTRUCTION FOR USE ENGLISH SQUEEGEE BLADE CHECK AND REPLACEMENT Clean the steel or aluminum squeegee, as shown in the previous paragraph. Check that the edges (E, Figure 26) of the front blade (C) and the edges (F) of the rear blade (D) lay down on the same level, along their length; if necessary adjust their height according to the following procedure: •... -
Page 29: Tank And Ball Float Cleaning, And Cover Gasket Check
INSTRUCTION FOR USE ENGLISH TANK AND BALL FLOAT CLEANING, AND COVER GASKET CHECK Drive the machine on a level floor. Ensure that the machine is off and the ignition key (42, Figure 3) has been removed. Open the recovery tank lid (A, Figure 29) to a 90degree position, and then remove the ball float filter (P) from the tank. Clean the recovery tank lid (A), recovery tank (B), and the float ball filter support frame (E). -
Page 30: Accessories/Options
INSTRUCTION FOR USE ENGLISH ACCESSORIES/OPTIONS In addition to the standard components, the machine can be equipped with the following accessories/options, according to the machine specific use: For further information concerning the above-mentioned optional accessories, contact an authorized Retailer. ACCESSORIES/OPTIONS See “Parts List” section Brush of different materials Battery tray On-board charger... -
Page 31: Error Code Of Display
INSTRUCTION FOR USE ENGLISH ERROR CODE OF DISPLAY Error# Error Description Notes Error 1 Valve Overload Valve short or overload Error 2 Brush Motor Overload Brush motor short or overload Error 3 Vacuum Motor Overload Vacuum motor short or overload Error 4 Traction Motor Overload Traction motor short or overload... -
Page 32: Scrapping
Plastic hose and plastic parts Electrical and electronic components (*) (*) Please contact our company service center destroying any electrical and electronic components. Machine material composition and recyclability AS7190TO weight per- Recyclable per- AS6690T/AS7690T Type centage% centage weight percentage% Aluminium... - Page 33 Company information: www.vipercleaning.eu info-eu@vipercleaning.com...
