YASKAWA AC Drive - Z1000
AC Drive for HVAC Fan and Pump
User Manual Supplement
Type: CIMR-ZU
Models: 200 V Class: 2.2 to 110 kW (3 to 150 HP)
400 V Class: 2.2 to 370 kW (3 to 500 HP)
This supplement replaces pages in the Z1000 User Manual and is intended for use
in Z1000 drives with standard software PRG:1013 and greater.
Refer to the "PRG" field on the drive nameplate for the drive software version.
PAGE REPLACEMENT:
Replace pages of TOEP C710616 45A Z1000 User Manual, Rev: 11-3 as explained
in the contents of this supplement.
MANUAL NO. TOEP YAISUP 04A
Models with Software PRG: 1013 and Greater
At initial power-up of a new Z1000,
the HOA keypad will prompt the user
to set the Real-Time Clock.
The clock must be set prior to drive
operation.
YYYY/MM/DD HH:MM
20
1
Second per month
+ 0 sec
NOTICE !
ALM
ALM
0/01/01 00:00

Advertisement

Table of Contents
loading

Related Manuals for YASKAWA Z1000

Summary of Contents for YASKAWA Z1000

  • Page 1 Models: 200 V Class: 2.2 to 110 kW (3 to 150 HP) 400 V Class: 2.2 to 370 kW (3 to 500 HP) This supplement replaces pages in the Z1000 User Manual and is intended for use in Z1000 drives with standard software PRG:1013 and greater.
  • Page 2 Every precaution has been taken in the preparation of this manual. Yaskawa assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained in this publication.

  • Page 3: Table Of Contents

    REVISION HISTORY....................25 Applicable Models: This document applies to all Z1000 drives with software version PRG:1013 or higher. The software version is listed on the nameplate located on the side of the drive, and can also be viewed by displaying monitor parameter U1-25.

  • Page 4: Replace Figure

    M– Heatsink N – Mounting hole Figure 1.6 Exploded view of IP00/Open-Type Enclosure Components (CIMR-Zo o 4A0361A) YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 5: Insert Figure

    H– USB port (type-B) O– Heatsink Figure 1.7 Exploded view of IP00/Open Type Enclosure Components (CIMR-Zo o 4A0414A) YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 6: Replace Panel Cut-Out Dimensions On Pages 42 And 43

    – – 18.6 2A0059 2A0075 2A0088 22.5 11.2 – – 21.9 – – – – 2A0114 YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 7 Drive HOA Keypad Comm Port Communication Cable Connector Figure 2.4 Communication Cable Connection YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 8: Replace Pages 51 And 52

    Figure 1 Figure 2 Max W2 Max W2 Max W2 Max W2 Figure 4 Figure 3 YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 9 0.18 – 487.2 4A0590A 26.38 44.88 14.57 17.32 0.24 8.66 43.70 0.59 5.91 0.18 – 487.2 YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 10: Replace Figure

    W/T3 – R/L1 S/L2 T/L3 U/T1 V/T2 W/T3 Figure 3.10 Main Circuit Terminal Block Configuration (continued) YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 11: Replace Table 3.3 Pages 79 And 80

    U/T1, V/T2, W/T3 5.4 to 6.0 <1> 8 to 2/0 4A0124 (48 to 53) -M, +M – – YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 12 YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 13: Replace Section 4.3 Beginning

    +488 in increments of 8. Pressing the down arrow key will decrease the number selected by the cursor from -504 to +488 in increments of 8. YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 14 Use the up and down arrow keys to scroll through display menu until the screen shows Programming “Programming”. HELP DATA YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 15 When o4-17 is set to 2, the Real-Time Clock data is cleared. A TIM fault will occur until the Real-Time Clock is set by o4– 17=1. YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 16: Replace Table

    Time delay Class J, T, or CC fuses sized at 175% of the drive input rating, or MCCB sized at 200% maximum of the drive input rating. Yaskawa recommends installing one of the following types of branch circuit protection to maintain compliance with UL508C. Semiconductor protective type fuses are preferred. Alternate branch circuit protection devices are also listed in Table 6.2...
  • Page 17 An external attachment can be used to project the heatsink outside of an enclosure to ensure that there is sufficient air circulation around the heatsink. Contact a Yaskawa sales representative or Yaskawa directly for more information on this attachment. Installing a Motor Thermal Overload (oL) Relay on the Drive Output Motor thermal overload relays protect the motor by disconnecting power lines to the motor due to a motor overload condition.

  • Page 18: Replace Table

    Select the appropriate capacity drive if operating the motor continuously above motor nameplate current. <2> The motor capacity (HP) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater than the motor current.

  • Page 19: Add Figure

    Drive operation between -10 °C and 40 °C allows 100% continuous current without derating. Operation between 40 °C and 50 °C requires output current derating. YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 20: Replace Table

    2A0075 FWH-225A 2A0088 FWH-225A 2A0114 FWH-250A 2A0143 FWH-275A 2A0169 FWH-350A 2A0211 FWH-400A 2A0273 FWH-450A 2A0343 FWH-600A YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 21 Verify the following installation conditions to ensure that other devices and machinery used in combination with this drive also comply with EMC guidelines. Install an EMC noise filter to the input side specified by Yaskawa for compliance with European standards. YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual...

  • Page 22: Replace Table

    FS5972-800-99 69.4 11.8 × 6.3 × 28.2 10.8 × 8.3 4A0590 Figure D.6 EMC Filter Dimensions YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 23: Replace Table

    <4> When using semiconductor fuses, Bussmann FWH fuses are required for UL compliance. <5> Consult factory. <6> Class L fuse is also approved for this rating. YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 24: Replace Table

    B – Drive (inside panel) E – Capacitor cover C – Opening to capacitors Figure D.9 Capacitor Cover YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...

  • Page 25: Revision History

    The technical specifications of Z1000 models CIMR-ZU4A0361A and November 2011 — CIMR-4A0414A are revised. First Edition. This Z1000 User Manual Supplement supports drive software September 2011 — — version PRG: 1013 and greater. YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 26 15 Revision History This Page Intentionally Blank YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 27 This Page Intentionally Blank YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement...
  • Page 28 AC Drive for HVAC Fan and Pump User Manual Supplement YASKAWA AMERICA, INC. 2121 Norman Drive South, Waukegan, IL 60085, U.S.A. Phone: (800) YASKAWA (927-5292) or 1-847-887-7000 Fax: 1-847-887-7310 http://www.yaskawa.com DRIVE CENTER (INVERTER PLANT) 2-13-1, Nishimiyaichi, Yukuhashi, Fukuoka, 824-8511, Japan Phone: 81-930-25-3844 Fax: 81-930-25-4369 http://www.yaskawa.co.jp...
