TRANSMISSION FLUID TEMPERATURE (TFT)
SENSOR TEMPERATURE VS. RESISTANCE
SPECIFICATIONS
Temperature
°C
-45
-40
-35
-30
-25
-20
-15
-10
-5
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
WSM082106
SECTION
7.2
Temperature Minimum Resistance
°F
-49
-40
-31
-22
-13
-4
5
14
23
32
41
50
59
68
77
86
95
104
113
122
131
140
149
158
167
176
© 2006 Workhorse Custom Chassis — All Rights Reserved
PAGE
8
Automatic Transmission – Allison
Nominal Resistance
ohms
128565 141951
95826 100735
68952
50153
36854
27345
20476
15467
11781
9045
6998
5458
4291
3398
2710
2173
1754
1424
1163
955.0
788.6
654.7
546.3
458.1
385.9
326.6
2007 W Series Chassis
Maximum Resistance
ohms ohms
155338
105644
72315 75679
52480 54807
38478 40103
28488 29631
21286 22097
16045 16624
12197 12612
9345
7219
5623
4413
3490
2779
2228
1797
1459
1191
977.1 999.2
806.5 824.5
669.3 683.9
558.3 570.2
467.9 477.8
394.1 402.2
333.3 340.1
9646
7441
5787
4536
3582
2849
2282
1840
1493
1218
