Test Description
The numbers below refer to the step numbers on the
diagnostic table.
3. This step tests ignition voltage.
5. This step tests for turbine speed not remaining at zero
in 5th range.
DTC P0735
Step
Schematic Reference: Automatic Transmission Controls Schematics
1
Did you perform the Diagnostic System Check - Vehicle?
2
Measure the transmission fluid level. Refer to Transmission Fluid Checking
Procedure .
Is the transmission fluid level correct?
3
1. Install the scan tool.
2. Turn ON the ignition, with the engine OFF.
IMPORTANT:
Before clearing the DTC, use the scan tool in order to record
Before clearing the DTC, use the scan tool in order to record
the Freeze Frame and Failure Records for reference. The
the Freeze Frame and Failure Records for reference. The
Clear Info function will erase the data.
Clear Info function will erase the data.
3. Record the DTC Freeze Frame and Failure Records.
4. Clear the DTC.
5. Using the scan tool, measure ignition voltage.
Is the voltage within the specified range?
4
1. Drive the vehicle under normal operating conditions.
2. Using the scan tool, monitor engine, turbine and output-speed readings.
Is speed sensor data erratic?
WSM082106
SECTION
7.2
Action
© 2006 Workhorse Custom Chassis — All Rights Reserved
PAGE
210
Automatic Transmission – Allison
Value
—
Go to Step 2
—
Go to Step 3
9-18 V
Go to Step 4
—
Go to the appropri-
ate speed sensor
DTC
2007 W Series Chassis
Yes
No
Go to Diagnostic
System Check -
Vehicle
Go to Transmission
Fluid Checking
Procedure
Go to DTC P0562
for low voltage or
DTC P0563 for high
voltage
Go to Step 5
