Acme Furniture 61283 Assembly Instruction

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts which may
have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware. Compare
with parts list to be sure all parts are present. If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service, please indicate the model number and code letter of part(s) needed.
PARTS LIST
NO DESCRIPTION
A BACK FRAME
B SEAT FRAME
C FRONT LEGS
D ARM CHAIR (L/ R)
STEP 1
11
ASSEMBLY INSTRUCTION
MODEL: #61283 ARM CHAIR
*** Do not fully tighten screws until fully assembled ***
SKETCH QTY
1PC
1PC
2PCS
2PCS
STEP 2
B
HARDWARE LIST
NO DESCRIPTION
1
ALLEN BOLT (Ø5/16*70MM)
2
ALLEN BOLT (Ø5/16*60MM)
3 ALLEN BOLT (Ø5/16*40MM)
SPRING WASHER (Ø5/16*2MM)
4
5 FLAT WASHER (Ø5/16*2MM)
6 ALLEN BOLT (Ø1/4*50MM)
7
ALLEN BOLT (Ø1/4*35MM)
8 SPRING WASHER (Ø1/4*2MM)
9 FLAT WASHER (Ø1/4*2MM)
10 ALLEN KEY (M4)
11 WOOD DOWEL (Ø10*30MM)
10
3
4
5
SKETCH
40MM)
40MM)
35MM)
QTY
4 PCS
4 PCS
2 PCS
10 PCS
10 PCS
2 PCS
2 PCS
4 PCS
4 PCS
1 Pc
1 Pc
