Omcan RE-CN-0045-HC Instruction Manual page 25

Model RE-CN-0052-HC
Item No. Description
61219 Evaporator Fan Blade V154/22 for 50052
Evaporator Fan Motor EM3020-28-C04 /
68809
110V for 50052
AA807 Right Bottom Hinge for 50052
AA808 Left Bottom Hinge for 50052
26884 K Clip for 50052
AA809 K Strip for 50052
AE915 Compressor (T6217Z) for 50052
AA687 Drain Pipe Cover for 50052
AA810 Bottom Hinge Axis for 50052
AA811 Middle Shelf for 50052
AE916 Inner Drain Pan for 50052
AA300 Condenser for 50052
AA813 Condenser Fan Motor for 50052
AA814 Condenser Fan Motor Blade for 50052
AB077 Condenser Fan Cover for 50052
26246 Caster with Brake for 50052
AA857 Upper Hinge for 50052
AE917 Shelf for 50052
26247 Caster without Brake for 50052
AE918 Back Grill for 50052
50052
Position Item No. Description
1 AE919 Air Pipe Protection Board for 50052
2 AA715 Axis Cover for 50052
3 AB970 Outer Drain Pan for 50052
Limited Block for Installation Board for
4 AB973
50052
5 AE920 Installation Board for 50052
6 AE894 Right Rail for Installation Board for 50052
7 AE892 Left Rail for Installation Board for 50052
8 AB974 Handle for Installation Board for 50052
9 AE921 Left Upper Hinge for 50052
10 AA830 Left Glass Door for 50052
11 AA686 Plastic Drain Pipe with Fixer for 50052
12 AE922 Supporting Board for 50052
13 AE923 Right Connecting Board for 50052
Left Connecting Board for Caster for
14 AE924
50052
15 AB109 Thermostat for 50052
16 AE925 Fixer for Inner LED Light for 50052
18 AA835 LED Inside Cabinet for 50052
19, 32 AA362 LED Light Switch for 50052
20 AA722 LED Light for 50052
21 AA836 Light Box Frame for 50052
Parts Breakdown
Position Item No.
22 AA837
23 AA695
24 AE926
25, 29 AB975
26 AA124
27 AE927
28 AE928
30 AA842
31 AA216
33 AB594
34 AB595
35 AA787
36 AE929
37 AA844
38 AE930
39 AA757
40 AB987
41 AB993
42 AA710
43 AE931
25
Description Position
Light Box Plate for 50052 44
Glass Door Handle for 50052 45
Thermostat Installation Plate for 50052 46
Waterproof Cover of Thermostat for
47
50052
Power Switch for 50052 48
Front Grill for 50052 49
Caster Supporter for 50052 50
Evaporator for 50052 51
Drain Tube for 50052 52
Filter for 50052 53
Filter Fixer for 50052 54
LED Power Supply for 50052 55
Gasket for 50052 56
Door Switch for 50052 57
Evaporator Cover for 50052 58
Evaporator Fan Motor Bracket for 50052 59
Right End Plate for Evaporator for 50052 60
Left End Plate for Evaporator for 50052 61
Evaporator Fan Motor Cover for 50052 62
Right Glass Door for 50052 63
