Summary of Contents for Omcan RE-CN-185B
- Page 1 Refrigerated Showcases Models RE-CN-185B, 255B, 325B Items 48564, 48565, 48566 Instruction Manual Revised - 02/12/2025 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
- Page 2 Table of Contents Model RE-CN-185B / Model RE-CN-255B / Model RE-CN-325B Section Page Disclaimer ----------------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------------- 5 - 7 Technical Specifications ------------------------------------------------------------------------------- 8 Operation ------------------------------------------------------------------------------------------------ 9 - 10 Maintenance ----------------------------------------------------------------------------------------------- 10...
- Page 3 Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO A FLOOR DRAIN.
- Page 4 If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.
- Page 5 Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
- Page 6 2 YEARS PARTS AND LABOUR & 5 YEARS PARTS ONLY ON COMPRESSOR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
- Page 7 Safety and Warranty Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use. Please see https://omcan.com/disclaimer for complete info. WARNING: The packaging components are classified as normal solid urban waste and can therefore be disposed of without difficulty.
- Page 8 Technical Specifications Model RE-CN-185B RE-CN-255B RE-CN-325B Item Number 48564 48565 48566 Power 275 W 305 W 400 W Capacity 185 L / 6.53 cu.ft. 255 L / 9 cu.ft. 325 L / 11.47 cu.ft. Exterior Material Glass / Plastic / Stainless Steel...
- Page 9 Operation BEFORE USE • Plug refrigerator into the 110-120V exclusive socket. • After the refrigerator is running, confirm that air suction/filtration is in order and that it is sufficiently cold. After checking to make sure the refrigerator is working properly, it may be used. DIGITAL TEMPERATURE CONTROLLER Small, integrated digital controller, which is applicable to the compressor of 1 HP.
- Page 10 Operation concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. The operation manual are not suitable for the persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge. Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
- Page 11 Noisy. The refrigerator is not level. The refrigerator contacts the wall or other matter. There is loose part in refrigerator. Contact Omcan for help if simple troubleshooting does not solve the problems. NOTE Following occurrences are not problems: • The murmur of water is heard when the refrigerator is working. It is a normal occurrence as the coolant is circulating in the system.
- Page 12 Parts Breakdown Model RE-CN-185B 48564...
- Page 13 Parts Breakdown Model RE-CN-185B 48564 Item No. Description Position Item No. Description Position Item No. Description Position AT905 Left Bracket for 48564 AT918 Back Bottom Pillar for 48564 AT934 Right Glass for 48564 AT906 Right Bracket for 48564 AT919 Ventilating Board for 48564...
- Page 14 Parts Breakdown Model RE-CN-255B 48565...
- Page 15 Parts Breakdown Model RE-CN-255B 48565 Item No. Description Position Item No. Description Position Item No. Description Position AT905 Left Bracket for 48565 AT955 Back Bottom Pillar for 48565 AT934 Right Glass for 48565 AT906 Right Bracket for 48565 AT956 Ventilating Board for 48565 AT935 Left Plate for 48565 AT907...
- Page 16 Parts Breakdown Model RE-CN-325B 48566...
- Page 17 Parts Breakdown Model RE-CN-325B 48566 Item No. Description Position Item No. Description Position Item No. Description Position AT905 Left Bracket for 48566 AT981 Ventilating Board for 48566 AT936 Right Plate for 48566 Upper and Bottom Door for AT906 Right Bracket for 48566 AT983 Back Panel for 48566 AT995...
- Page 18 Electrical Schematics Model RE-CN-185B 48564 Model RE-CN-255B 48565 Model RE-CN-325B 48566...
- Page 19 Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
- Page 20 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
