Bogen PCM2000 Specifications

Zone Paging
System
Model PCM2000
• One-zone to 99-zones of simultaneous high-
power and low-power paging
Features
• Up to 32 paging zone groups
• Universal telephone interface designed for direct
connection to loop start and ground start trunks,
to PBX or KEY paging ports which supply DTMF
capability, and to analog T/R lines
• Modular integration assures reconfiguring and
expansion with minimum time and expense
• Optional talkback paging and time-triggered
signaling events with PCMTBM module
Technical
Specifications
Registered under Part 68 of FCC Rules
Ringer Equivalence: 1.0B
Operating Voltage: 12V DC
Operating Current (max.): 1.5A (9-zone system)
Audio Power Capability: 250W/9-zone system
Operating Temperature: 25 to 100°F
Operating Humidity: 0 to 90% noncondensing
Dimensions (single module): 1-
Shipping Weight (single module): Approximately 2 lb.
• Field programmable using DTMF and DIP
switches
• Signaling features include night ringer zone group,
emergency/shift change zone group, code call
zone group
• Emergency All-Facility Override Paging
• Background music assigned per zone; Local
Background music sourcing capability
• Relay drivers and Aux contacts included
• Allows total system amplifier power of up to
250W
/ / /
" W x 7- " H x 4-
1 1 1
2 2 4
Specifications subject to change without notice.
© 1995 Bogen Communications, Inc.
Part No. 54-7833-03C Printed in U.S.A. 0303
" D
