Bogen DCM290P Specifications

MULTI-DISC CD PLAYER
This 5-Disc CD Player is capable of loading and removing discs without
interrupting play. Plays audio CDs as well as CD-R/RW discs with MP3
and WMA files. A rack mounting kit is included.
P r o d u c t F e a t u r e s :
• 5-Disc CD changer
• Load or remove discs without
interrupting play mode
• Stereo output via analog RCA jacks
and digital output via coaxial and
optical jacks
• Program up to 32 tracks from up to
five separate discs
• MP3 and WMA decoders
• Infrared remote control
*
This product is covered by original manufacturer's 1-Year Limited Warranty.
Please contact Customer Service for warranty information on this product.
DIGITAL STEREO TUNER
DST1
The DST1 Digital Tuner incorporates a digital PLL-synthesized tuner for precise reception
of FM and AM signals. The DST1 features the ability to store up to 60 total presets (FM and
AM). It is designed for shelf- or rack-mounted installation and is one rack space (1 RU)
high. Removable rack ears are included with the unit.
P r o d u c t F e a t u r e s :
• PLL-synthesized tuning with digital readout
• 60 Presets total (FM and AM), with scan feature
• Stereo and Mono outputs
• Volume control (rear panel-mounted)
• Connectors for 75-ohm FM, 300-ohm FM,
and AM loop antennas
• FM dipole and AM loop antennas included
• Bright alphanumeric, fluorescent display panel
• Operates from nominal 120V AC, 60 Hz
• Handheld remote control
• Stereo output cable
• Shelf- or rack-mounted installation, one rack space
high (1 RU, removable rack ears included)
• Listed to UL Standard 60065 for US and Canada
5-Disc
CD Player
DCM290P
• 3-mode random playback (full random,
program random, disc sequential random)
• Includes rack mount kit (3 rack spaces)
• UL and C-UL listed
Power Requirements:
17-1/8" W x 4-3/4" H x 15-3/4" D
Dimensions:
(without Rack Kit)
Product Weight:
Remote
Control
(included)
Output Connections
The DCM290P provides separate stereo
outputs via analog RCA connectors and
digital optical and coaxial connectors.
MP3/WMA Decoders
MP3/WMA decoders play finalized CD-
*
R/RW discs containing MP3 or WMA
audio files. A single CD-R/RW disc can
contain up to 10 times more tracks than an
ordinary audio CD. Installations requiring
long-play background music are excellent
applications for CD-R/RW discs contain-
ing a large number of MP3 files.
Playback Modes
Audio track selection can be configured in
a variety of ways for playback. Tracks can
be played back sequentially or randomly,
manually or programmed (up to 32 tracks)
from any one or up to five loaded discs.
Random playback functions include ran-
dom playback of tracks from one, all or
programmed tracks from the loaded discs.
120V AC
Once all tracks are played back in random
order, "repeat playback" plays back the
same selected tracks in a different random
order.
13 lb.
Intelligent Disc Scan
When using the remote control, the disc
skip button rotates the carousel tray
clockwise or counterclockwise when
searching for a disc for faster playback.
Antenna Connections
Anyone who has installed a tuner inside
an industrial building knows that radio
signals don't penetrate too far into these
steel-laced structures. Because the DST1
is designed for industrial installations, it
contains inputs for both external 300-
ohm (twin line) and 75-ohm (coaxial)
antenna feeds. The 75-ohm input uses
an "f" connector and can receive feeds
from antenna distribution systems or
cable systems.
Whether sitting on a shelf or mounted in
a rack, the DST1 is a great choice for an
industrial-grade tuner.
Power Requirements:
Dimensions:
Product Weight:
FM GND GND AM
FM
Ω
300Ω AM LOOP
120V AC nominal @ 60Hz
16-7/8" W x 1-3/4" H x 10" D
5 lb.
