Unibor E100 PLUS Assembly & Parts List

Unibor E100 PLUS Assembly & Parts List
14
32
18
65
33
36
35
34
11
12
CONTROL PANEL ASSEMBLY
INCLUDES ITEMS 47 TO 57
3 67 7 4 5 6 43 46
8 31
2
27
ITEM NO PART NO
1 M0005BLU MT50 BODY (CAPRI BLUE)
2 M0033
3 20355
4 M0103
5 M0442
6 M0813
7 M0833
8 M0042
9 M0071
10 M0081
11 20346
12 10082
42
13 M0224
14 M0443
15
15 10231
16 40026
44
17 10237-1
17 KBL 01
66
18 EIB23
18 EIB24
45
18 EIB25
18 EIB26
58
19 STRAP01
20 KEY01
59
21 KEY03
22 KEY04
9
23 DRIF02
24 CASE14
25 BOX01
10
26 VISO10
27 M0242N
60
28 10093
29 10094
13
30 10089
31 MM1-17
32 40025
33 ARBO03-A
34 10205A
35 SPRI01
36 10073
1
42 30046
43 10076C
68
44 50015C
45 BD029
14
46 10076
47 MM1-1
17
48 MM1-2
49 MM1-10
50 MM1-3
51 MM1-4
52 MM1-5
53 MM1-6
54 MM1-7
55 MM1-11
56 MM1-16
57 MM1-13
58 M5-NUT
59 SC620CAP M6 x 20 CAP SCREW
60 SC3TAP
DESCRIPTION QTY
1
MAGNET BASE (LARGE) 1
EIBENSTOCK CRADLE 1
BRASS RAIL (MT50) 2
G.F.S. (MT50) 1
TOP PLATE (MAGTRON DOVETAIL) 1
RACK (MT50) 1
PINION - MAGTRON (LARGE) 1
PINION END CAP (SHALLOW) 1
BUSH (PINION) 2
HANDLE (12mm LARGE) 3
HANDLE KNOB (12mm KNOCK ON) 3
WARNING PLATE (MT50) 1
CONDUIT (MAGTAP M13) 1
M16 STRAIN RELIEF CABLE GLAND 1
M16 PUSH FIT GLAND 1
CABLE YELLOW (110V) 1
CABLE BLACK (240V) 1
EIBENSTOCK UNI 4 DRILL - 110V 1
EIBENSTOCK UNI 4 DRILL - 240V 1
EIBENSTOCK UNI 4 FR DRILL - 110V 1
EIBENSTOCK UNI 4 FR DRILL - 240V 1
POLYESTER WEBBING SAFETY STRAP 1
ALLEN KEY 2.5MM 1
ALLEN KEY 4MM 1
ALLEN KEY 5MM 1
DRIFT (No.3 M/TAPER) 1
CARRYING CASE UNIBOR - PLASTIC 1
BOX (UNIBOR SLEEVE) 1
SAFETY GUARD ( UNI 3 ) 1
LARGE SWITCH PLATE NEW 1
M6 X 35 GUARD THUMB SCREW 2
M6 GUARD SPACER 2
LARGE 2 LEG GUARD GUIDE 2
PCB SUPPORT PLATE 1
PG9 PUSH FIT GLAND 1
No3 MT ARBOR BODY 1
ARBOR EJECTION PLUG (M/TAPER) 1
ARBOR SPRING (M/TAPER) 1
M10 X 10 SET SCREW(FLAT POINT) 2
LARGE OIL CUP ASSEMBLY 1
OILFEED BRACKET 1
1/8" BSP - 6MM PUSH FIT CONNEC 2
6mm OIL PIPE (OIL FEED ASSY) 1
OIL CUP RETAINING CLIP 1
MM1 MAGNET BUTTON - YELLOW 1
MM1 MOTOR BUTTON - GREEN 1
MM1 POWER BUTTON - RED 1
MM1 L.E.D. GROMMET 3
MM1 LED BOARD - C/W LEDs 1
MM1 REPLACEMENT PCB 1
MM1 3 PIN PLUG 1
MM1 4 PIN PLUG 1
MM1 HEAT CONDUCTOR 3
STAND OFF CLIP FOR NEW PANEL 3
NEW PANEL INSULATING BUSH 2
M5 NUT 5
9
M3 SELF TAPPING SCREW 8
