- Page 1 Ross Video Limited 8-Keyer Module Installation Guide...
- Page 2 Notice The material in this guide is furnished for informational use only. It is subject to change without notice and should not be construed as commitment by Ross Video Limited. Ross Video Limited assumes no responsibility or liability for errors or inaccuracies that may appear in this guide.
- Page 3 To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Ross Video encourages you to use the appropriate take-back systems. These systems will reuse or recycle most of the materials from your end-of-life equipment in an environmentally friendly and health conscious manner.
-
Page 4: Package Contents
Package Contents The contents of a single 8-Keyer Module upgrade kit is listed below. If any items are missing, or damaged, contact Ross Video Technical Support. Part# Item 4800AR-127A 8-Keyer Module 727-024R Module Control Link Cable (Black, CAT5e) 4 • Package Contents... - Page 5 8-Keyer Module Installation To install the 8-Keyer module for the Vision control panel, you must power down the control panel, disconnect the communications cables, remove the Keyer module, install the new module, and then connect the power and communications cables. A single 8-Keyer module can be installed in the control panel.
- Page 6 signals to and from the module, as well as the other modules in the same row. Remove the Retaining Bolts located at each corner of the Keyer module and keep them in a safe place. A ¼ inch hex driver or wrench is required.
- Page 7 8-Keyer Module Setup With the 8-Keyer module installed and cabled, the Vision switcher must be set up to properly communicate with the 8-Keyer module. Refer to your Vision Engineering Manual for information on upgrading your PMCs and assigning the 8-Keyer module to a panel row. 8-Keyer Module Setup •...
- Page 8 613 • 349 • 0006 613 • 652 • 4425 General Information solutions@rossvideo.com E-MAIL Technical Support techsupport@rossvideo.com 8 John Street, Ross Video Limited Iroquois, Ontario, Canada K0E 1K0 POSTAL SERVICE P.O. Box 880, Ross Video Incorporated Ogdensburg, New York, USA...
