Reentrant horn loudspeaker

Advertisement

Reentrant Horn
Loudspeaker
Model IH8A
The Bogen Model IH8A is a double reentrant horn-type loudspeaker designed for paging applications.
Description
Excellent intelligibility, handsome compact styling, and all metal, weatherproof construction make the model
IH8A perfect for use indoors or outdoors with Bogen sound equipment.
A detachable mounting bracket, which includes a wing-nut locking device, provides precise positioning of
the horn in the vertical and horizontal planes.The unit is finished in textured mocha enamel.
• High intelligibility and efficiency
Features
• Weatherproof, all metal construction
• 12" connecting cable for easy installation
The loudspeaker shall be a Bogen Model IH8A reentrant horn-type loudspeaker, or approved equivalent,
providing a frequency response from 350Hz to 12kHz. Input impedance shall be 8 ohms. Rated power out-
put shall be 15 watts. Dispersion shall be 130°. Sound pressure level, measured four feet on axis at rated
Architects
output, shall be at least 120dB.
&
Engineers
The loudspeaker shall be of weatherproof, all metal construction, with driver enclosed within a waterproof

Specifications

housing. A 12-inch connecting cable shall be provided.
An all-purpose mounting bracket shall provide precise positioning in the vertical and horizontal planes.
Bracket and loudspeaker shall be finished in textured mocha enamel. The unit shall measure 6-1/4" dia. x
6"D. The product weight shall be 2-1/2 lbs.
Specifications
Power Rating:
Frequency Response:
Input Impedance:
Dispersion:
Sound Pressure Level:
Dimensions:
Product Weight:
15 watts
350Hz to 12kHz
8 ohms
130°
120dB @ 4 feet on axis with
15-watt input at 1000Hz
6-1/4" diameter bell x 6"D
2-1/2 lbs.
50 Spring Street, Ramsey, NJ 07446, USA
201-934-8500 • FAX: 201-934-9832 • www.bogen.com
Part No. 54-7774-03R2 Printed in U.S.A. 0105
Specifications subject to change without notice.
© 1998 Bogen Communications, Inc.
