Manning Desk
Model # SPCA-MMPD
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2016-10-19 Rev. 0001-C Factory: HESLTD
1-866-942-5362
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Related Manuals for Whalen SPCA-MMPD
Summary of Contents for Whalen SPCA-MMPD
- Page 1 LOT NUMBER: DATE PURCHASED: / Manning Desk Model # SPCA-MMPD ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
-
Page 2: Special Note
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Manning Desk (SPCA-MMPD) MADE IN CHINA MAXIMUM LOAD 200 lb. - Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH DAMP CLOTH.
- Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Desk Top (1) B- Desk Left Side Panel (1) C- Desk Right Side Panel (1) D- Modesty Panel (1) (1) Large Cam Lock (11+1 extra) (2) Cam Bolt (11+1 extra) (3) M8 x 30 mm Wood Dowel (6+1 extra)
- Page 5 Assembly Instructions A/B/C 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Locate the Desk Top (A), Desk Left and Right Side Panels (B and C) with the holes facing up. Securely screw the Cam Bolts (2) into the designated small holes by a Phillips screwdriver, as shown.
- Page 6 Assembly Instructions 4. Glue four M15 x 60 mm Wood Dowels (4) and two M8 x 30 mm Wood Dowels (3) into the top inner holes of the Desk Side Panels (B and C) and the Modesty Panel (D). As shown. DO NOT insert the Wood Dowels into the Cam Bolt holes.
-
