Leadenhall Lateral File
Model # SPUS-LDHL-LF
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Mfg., Inc.
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
LOT NUMBER:
DATE PURCHASED: /
Page 1
/
Factory No. 15548
Advertisement
Related Manuals for Whalen SPUS-LDHL-LF
Summary of Contents for Whalen SPUS-LDHL-LF
- Page 1 LOT NUMBER: DATE PURCHASED: / Leadenhall Lateral File Model # SPUS-LDHL-LF ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
-
Page 2: Special Note
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Mfg., Inc. CATALOG: Leadenhall Lateral File (SPUS-LDHL-LF) DATE OF MANUFACTURE: April 2014 MADE IN CHINA MAXIMUM LOAD 100 lb. - Page 3 Model # SPUS-LDHL-LF Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.
- Page 4 Model # SPUS-LDHL-LF Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (1) B- Left Side Panel (1) C- Right Side Panel (1)
- Page 5 Model # SPUS-LDHL-LF Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Small Cam Lock (2) Large Cam Lock (3) Small Cam Bolt (4) Large Cam Bolt...
- Page 6 Model # SPUS-LDHL-LF Drawer Assembling 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Pick up the Ball Bearing Slides (S) and separate the Slide Runners for the following steps. Extend the Slide Runner all the way forward.
- Page 7 Model # SPUS-LDHL-LF Drawer Assembling 6. Connect Drawer Left and Right Side Panels (K and L) to the Drawer Front (I) by engaging four Small Cam Locks (1) (Refer to page 3 on Cam Lock system operation supplement). As shown. Make sure that the grooves line up with each other.
- Page 8 Model # SPUS-LDHL-LF Drawer Assembling 8. Slide one Drawer Bottom Panel (N) into the grooves between the Drawer Side Panels (K and L) until fully inserted into the Drawer Front (I). Make sure the finished surface will face up. As shown.
- Page 9 Model # SPUS-LDHL-LF Drawer Assembling 10. Turn the assembled drawer upright. 11. Attach two Handles (11) to the outside of the Drawer Front (I) using four provided Handle Bolts (12). 12. Repeat the same procedure to assemble the other drawer.
- Page 10 Model # SPUS-LDHL-LF Assembly Instructions 15. Fit Guide Rails (P and Q) onto the Drawer Back Panels (J) and the Side Panels (K and L) respectively with the high side facing inward. As shown. 16. Hook two File Hangers (R) onto the high edge of Guide Rails (O and P). Slide the File Hangers left and right to keep hanging files organized.
- Page 11 Model # SPUS-LDHL-LF Assembly Instructions 18. Using the pilot holes as a guide, attach the separated Slide Tracks (S) to the Left and Right Side Panels (B and C) respectively, using three 1/2” Screws (6) per slide track. As shown. Make sure the slide opening is against the closest edge of the Side Panels (B and C).
- Page 12 Model # SPUS-LDHL-LF Assembly Instructions 20. Combine Upper Back Panel (D) and Lower Back Panel (E) together with three Wood Dowels (5). As shown. 21. Attach the Left Side Panel (B) to the assembled Back Panels (D and E) using four Large Cam Locks (2) and two Wood Dowels (5).
- Page 13 Model # SPUS-LDHL-LF Assembly Instructions 22. Fasten Bottom Stretcher (G) and Middle Crossbar (H) to the Left Side Panel (B) using two Large Cam Locks (2) and two Wood Dowels (5). As shown. Make sure that the Cam Locks will face the floor.
- Page 14 Model # SPUS-LDHL-LF Assembly Instructions 24. Insert six Wood Dowels (5) into the top inner holes of the Side Panels (B and C) and the Upper Back Panel (D). Position the Top Panel (A) onto the inserted Wood Dowels (5) and lock with seven Cam Locks (2).
- Page 15 Model # SPUS-LDHL-LF Assembly Instructions 26. Secure the Bottom Molding (F) to both Side Panels (B and C) by attaching two Corner Connectors (9) at the joints, using two 1/2” Screws (6) per connector. As shown. 27. Gently tap two Floor Protectors (10) to the bottom of each Side Panel (B and C). As shown. Make sure that the Floor Protectors rest on the proper location for avoiding any damage or crack.
- Page 16 Model # SPUS-LDHL-LF Assembly Instructions 28. Ask for assistance to stand the unit upright. 29. Put the bottom wing of the Butterfly Locking Kit (13) forward, then fully slide the assembled bottom drawer into the frame. As shown. NOTE: The bottom drawer has a Lock Holder installed on the upper portion of the Left Side Panel (K).
- Page 17 Model # SPUS-LDHL-LF Assembly Instructions 30. Put the top wing of the Butterfly Locking Kit (13) forward, then fully slide the assembled Top Drawer into the frame. As shown. 31. Position the assembled unit at the desired location against a wall. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraint to the unit and the wall.
-
