Raine Bookcase White
Model # SPLS-RBK-WH
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Manufacturing
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
Date 2014-11-20 Rev. 1 Factory: DOGULU
1-866-942-5362
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 15548
/
Advertisement
Related Manuals for Whalen SPLS-RBK-WH
Summary of Contents for Whalen SPLS-RBK-WH
- Page 1 LOT NUMBER: DATE PURCHASED: / Raine Bookcase White Model # SPLS-RBK-WH ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 Model # SPLS-RBK-WH Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 3 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS.
- Page 3 Model # SPLS-RBK-WH Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Side Frame (2) B- Top Panel (1) C- Shelf (3) D- Back Panel (1)
- Page 4 Model # SPLS-RBK-WH Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Locate the Side Frames (A) and Top Panel (B) with the holes facing up. Securely screw the Cam Bolts (2) into the designated small holes as shown in the illustration.
- Page 5 Model # SPLS-RBK-WH Assembly Instructions 6. Insert four Wood Dowels (3) into the top inner holes of the Side Frames (A). Position the Top Panel (A) onto the inserted Wood Dowels (3) and attach it in place by engaging four Cam Locks (1). As shown.
- Page 6 Model # SPLS-RBK-WH Assembly Instructions 9. Ask for assistance to stand the unit upright and position it at the desired location against a wall. 10. Plug the Cam Lock Covers (5) onto the visible Cams Locks to conceal the Cams.
-
Page 7: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
