Greenwich Computer Desk with Hutch (Hutch)
Model # SPCA-GDH
ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP
POINTS, SHARP EDGES AS RECEIVED. 2 PEOPLE RECOMMENDED.
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Mfg., Inc.
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com

1-866-942-5362
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 16015
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Greenwich Computer Desk with Hutch and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Whalen Greenwich Computer Desk with Hutch

Summary of Contents for Whalen Greenwich Computer Desk with Hutch

  • Page 1 LOT NUMBER: DATE PURCHASED: /                                               Greenwich Computer Desk with Hutch (Hutch) Model # SPCA-GDH ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP POINTS, SHARP EDGES AS RECEIVED. 2 PEOPLE RECOMMENDED. If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased.
  • Page 2 4. Plug the Cam Lock Cover into the cross slot of the Cam Lock to conceal the Cam. You are now ready to assemble the KD unit. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 2 Factory No. 16015...
  • Page 3 L- Door Panel (2) M- Adjustable Shelf (2) N- Left Back Panel (1) O- Right Back Panel (1) P- Middle Back Panel (1) 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 3 Factory No. 16015...
  • Page 4 (13) Door Hinge (4 sets) Glue (1) Touch-up Pen (1) Tipping Restraint Hardware Kit (2) (Inside Plastic Bag) Tools required: Phillips screwdriver (not provided). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 4 Factory No. 16015...
  • Page 5 D) respectively, using two 1/2” Zinc Screws (4) per hinge. As shown. Make sure that the slot on the top of Hinge Base faces the closest edge. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 5 Factory No. 16015...
  • Page 6 7. Repeat the same procedure to attach the Left Inner Panel (C) at the other end. 8. Securely screw two Cam Bolts (2) into the designate small holes on the Left Inner Panel (C), as shown. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 6 Factory No. 16015...
  • Page 7 9. Repeat steps 4-7 for the right hutch stand substituting parts D for B and E for C. 10. Securely screw two Cam Bolts (2) into the designate small holes on the Right Inner Panel (E), as shown. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 7 Factory No. 16015...
  • Page 8 Large Fixed Shelf (H) using four 1-1/2” Screws (5). As shown. Make sure that the raw edges point towards the same direction. Tighten the screws with a Phillips screwdriver. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 8 Factory No. 16015...
  • Page 9 Cam Bolt holes. Position the Hutch Top Panel (A) onto the inserted Wood Dowels (3) and attach it in place by engaging 12 Cam Locks (1). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 9 Factory No. 16015...
  • Page 10 Gently hammer the 3/4” Ring Shank Nails (7) through the pre-drilled small holes on the Back Panels. NOTE: We recommend attaching back panel with the nails at the corners first. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 10 Factory No. 16015...
  • Page 11 22. Open and close the doors to make sure they are aligned and shut correctly. If necessary, adjust the screws for a good fit. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 11 Factory No. 16015...
  • Page 12 27. To secure the units in place, attach the Metal Brackets (9) over the drilled holes using four 5/8” Screws (6) per Metal Bracket. Tightly fasten all the screws with a Phillips screwdriver. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 12 Factory No. 16015...
  • Page 13 Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Mfg., Inc. Page 13 Factory No. 16015...

  • Page 14: Care And Maintenance

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.

This manual is also suitable for:

Spca-gdh
