Turing 48" Corner Desk with Power Strip
ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP
POINTS, SHARP EDGES AS RECEIVED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # SPLS-TU48CD
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2020-01-29
LOT NUMBER:
DATE PURCHASED: /
Rev. 0001-A
/
Advertisement
Related Manuals for Whalen SPLS-TU48CD
Summary of Contents for Whalen SPLS-TU48CD
- Page 1 LOT NUMBER: DATE PURCHASED: / Turing 48" Corner Desk with Power Strip Model # SPLS-TU48CD ADULT ASSEMBLY REQUIRED DUE TO THE PRESENCE OF SMALL PARTS, SHARP POINTS, SHARP EDGES AS RECEIVED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased.
-
Page 2: Special Note
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Turing 48" Corner Desk with Power Strip MODEL # SPLS-TU48CD MAXIMUM LOAD 22.7 kg / 50 lb. - Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 6 and 7 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH DAMP CLOTH.
- Page 4 FURNITURE POWER DISTRIBUTION CENTER IMPORTANT SAFETY INSTRUCTIONS Carefully read all instructions before installing and operating fixture IF YOU HAVE ANY QUESTIONS REGARDING THE PROPER INSTALLATION CONSULT A QUALIFIED ELECTRICIAN. TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS, PLEASE FOLLOW THE BELOW: ...
-
Page 5: Specifications
Model No: HG2000-DBU ! If USB Hub Current Limit Exceeded appears on your Company: Whalen Furniture Manufacturing screen, disconnect the affected USB device, click NOTE: This equipment has been tested and found to Reset on the screen, and reconnect the device. - Page 6 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Desk Top (Qty. 1) B- Bookcase Left Side Panel (Qty. 1) C- Bookcase Right Side Panel (Qty. 1) D- Bookcase Top Panel (Qty.
- Page 7 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) 1/4” x 12 mm Bolt (2) Lock Washer (3) Flat Washer (Qty. 27+1 extra) (Qty. 27+1 extra) (Qty.
- Page 8 Assembly Instructions NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch.
- Page 9 Assembly Instructions The cam locks face inward 4. Align and attach the Upper Shelf (F) to the Back Panel (H) by engaging three Cam Locks (4). (Refer to page 3 on Cam Lock system operation supplement). The cam bolts point toward the side with cut-out 5.
- Page 10 Assembly Instructions 6. Align and attach the Lower Shelf (G) to the previous assembly by engaging five Cam Locks (4). 7. Securely screw the Cam Bolts (5) into the designated small holes on the Shelves (F and G) using a Phillips screwdriver.
- Page 11 Assembly Instructions This end lines up with each other. 8. Using the pilot holes as a guide, align and attach two Desk Top Stretchers (L) to the Desk Top (A) with eight 32 mm Screws (7). 9. Glue four Wood Dowels (6) into the inner holes of Desk Top (A).
- Page 12 Assembly Instructions 10. Using the wood dowels as a guide, align and attach the Desk Top (A) to the Middle Partition Panel (J) by engaging two Cam Locks (4). 11. Fasten the assembled Desk Top Stretchers (L) to the Back Panel (H) by attaching eight 12 mm Bolts (1) and eight Washers (2 and 3).
- Page 13 Assembly Instructions 12. Align and attach the Bookcase Right Side Panel (C) to the assembled Shelves (F and G) and Back Panel (H) by engaging six Cam Locks (4). 13. Align and attach the Bookcase Left Side Panel (B) to the assembled unit by engaging eight Cam Locks (4).
- Page 14 Assembly Instructions 14. Glue the Wood Dowels (6) into the inner holes of assembled Side Panels (B and C), Upper and Lower Partition Panels (I). 15. Align and attach the Upper/Lower Partition Panels (I) to the assembled Shelves (F and G) respectively by engaging two Cam Locks (4) per panel.
- Page 15 Assembly Instructions 16. Securely screw the Cam Bolts (5) into the designated small holes on the Panels (D and E) using a Phillips screwdriver. 17. Align the large holes on Bookcase Top and Bottom Panels (D and E) with the inserted wood dowels (6) and press them together.
- Page 16 Assembly Instructions 18. Attach two Base Short Supports (N) between the Base Long Supports (M) with eight 12 mm Bolts (1) and eight Washers (2 and 3). 19. Using the pilot holes as a guide, align and attach the assembled Base to the Bookcase Bottom Panel (E) with ten 32 mm Screws (7).
- Page 17 Assembly Instructions 20. Ask for assistance to stand the assembled unit upright. 21. Attach the Desk Side Frame (K) to the Desk Top (A) with eleven 12 mm Bolts (1) and eleven Washers (2 and 3). 22. Feed the wire of Power Center (O) through the cutout on the Back Panel (H) and push into the cutout. Make sure the wire is not pinched.
- Page 18 Assembly Instructions Floor leveler 23. Cover the visible cam locks with the PVC Covers (9) provided. 24. Position the unit at the desired location against a wall. If necessary, adjust the pre-attached floor levelers at the bottom of the Desk Side Frame (K) and Base Supports (M) to level the unit. 25.
-
Page 19: Quality Guarantee
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
