Bogen AMBSL1 Technical Specifications

Self-Amplified
Metal Box
AMBSQ1, AMBSL1
Bogen's AMBSQ1 and AMBSL1 speakers feature an all-steel surface-mounted enclosure with an 8" cone loud-
Description
speaker, built-in 1W amplifier, and volume control.The AMBSQ1 is suitable for ceiling or wall mounting.The
AMBSL1 is designed primarily for wall mounting and its face is angled downward by 12.5 degrees. A detach-
able volume control knob on the grille allows individual adjustment of paging level at each speaker location.
• Rugged all-steel surface-mounted enclosure
Features
• Full-range 8" cone speaker for excellent
intelligibility
• Self-contained 1-watt amplifier
Cone Diameter:
Technical
Magnet Weight:
Specifications
Power Rating (max.):
Typical Operational Current:
Supply Voltage:
Frequency Response:
Input Impedance:
Typical Input Sensitivity:
Maximum Sound Pressure Level:
Dispersion (min.):
Product Weight:
Enclosure Size:
Construction:
The speaker shall be a Bogen Model _____ (specify
Architect
AMBSQ1 or AMBSL1) amplified loudspeaker, or
equivalent, utilizing an 8" cone and a built-in amplifier
& Engineer
with volume control.The frequency response shall be
Specifications
110 Hz to 15 kHz.
For all models sensitivity shall be 125 mV and input
impedance shall be 2000 ohms.The loudspeaker shall
be powered by a suitable 24V DC power supply and
shall consume 1 CU (50 mA) at typical operational
levels. Sound pressure level, measured 1 meter on
axis with 1W output shall be at least 92 dB.
Specifications subject to change without notice.
© 2006 Bogen Communications, Inc.
Part No. 54-8023-34A Printed in U.S.A. 0609
Speakers
Models
AMBSQ1
Shown with
Volume Knob
• Interfaces with standard 600-ohm telephone line
• Built-in volume control with detachable knob
• Mounting hardware included (toggle bolts, wood
screws, pluggable screw terminals, volume knob)
8" (paper)
6 oz.
1W
1 CU (50 mA)
24V DC
110 Hz -15 kHz
2000 ohms
125 mV
92 dB @ 1 Meter on axis, 1W output
100°
9 lb.
AMBSQ1 - 11-5/8" W X 11-5/8" H X 4-1/4" D;
AMBSL1 - Top: 11-5/8" W X 11-3/8" H X 5-3/8" D;
Bottom: 11-5/8" W X 11-3/8" H X 3-1/8" D
Painted steel enclosure
The speaker enclosure shall be full steel construction
and allow for surface mounting. The enclosure shall
be painted off-white and measure ___ (specify 11-
5/8" W X 11-5/8" H X 4-1/4" D for AMBSQ1 or 11-
5/8" W X 11-5/8" H X 5-3/8" D [top] and 11-5/8" W
X 11-5/8" H X 3-1/8" D [bottom] for AMBSL1).
Product weight shall be 9 lb.
AMBSL1
Front face shall be angled downward by 12.5 degrees.
50 Spring Street, Ramsey, NJ 07446, U.S.A.
201-934-8500 FAX: 201-934-9832
www.bogen.com
AMBSL1
Shown with Volume
Knob detached
