Installation Guides

• Use the camera skin for better weatherproof
performance when you install the camera
outdoors.
• Install the camera 2-3 meters (7-10 ft)
above ground. The detection range of
the motion sensor would be maximized
at such a height.
• For effective motion detection,
please install the camera angularly.
NOTE: If a moving object approaches the PIR
sensor vertically, the camera may fail to
detect motion.
7 English
A B
Mounting
Height:
2-3 Meters
PIR Detecting Distance:
2-10 Meters
θ
Mount the Camera
into a Wall
1
Press the button to release the
plate from the security mount.
3 4
Lock the security mount on its Press the security mount
plate. (Make sure the top edge button until its plate clicks into
of the plate is inserted into the the mount.
mount.)
2
Screw the security mount
plate into the wall.
5
Screw the camera, adjust its
angle and tighten the knob to
lock it.
English 8
